Acer Veriton X X480G Intel® Pentium® E5400

3 GB DDR3-SDRAM 500 GB Intel® GMA X4500 Windows 7 Professional SFF PC

Model X480GPart no. PS.V97E2.017EAN 4718235622114

104 specifications

ProcessorIntel® Pentium®
Memory3 GB
Storage500 GB
GraphicsIntel® GMA X4500
TypePC
OSWindows 7 Professional

See all specifications

Overview

Processor: Intel® Pentium®
Memory: 3 GB
Storage: 500 GB
Graphics: Intel® GMA X4500
Type: PC
OS: Windows 7 Professional

Brand: Acer
Category: PCs/Workstations
Model: X480G
Part numbers: PS.V97E2.017, PS.VCKE3.013, PS.V97E3.177, PS.V97E3.015, PS.V97E3.016, PS.V97E9.002 +7 more
EAN / UPC: 4718235622114, 4718235621995, 4718235622091, 4712842059400 +7 more
Also known as: Acer Veriton X X480G Intel® Pentium® E5400 3 GB DDR3-SDRAM 500 GB Intel® GMA X4500 Windows 7 Professional SFF PC

Specifications

104 specifications in 16 groups

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Pentium®
Processor model	E5400
Processor cores	2
Processor threads	2
Processor frequency	2.7 GHz
Processor cache	2 MB
Processor cache type	L2
Processor front side bus	800 MHz
Bus type	FSB
FSB Parity	No
Processor lithography	45 nm
Processor operating modes	64-bit
Processor series	Intel Pentium E5000 Series for Desktop
Processor codename	Wolfdale
Thermal Design Power (TDP)	45, 65
Tcase	74.1 °C
Number of processors installed	1
Processor socket	LGA 775 (Socket T)
Number of Processing Die Transistors	228 M
Processing Die size	82 mm²
CPU multiplier (bus/core ratio)	13.5
Stepping	R0
ECC supported by processor	No

Memory

Specification	Value
Internal memory	3 GB
Maximum internal memory	8 GB
Internal memory type	DDR3-SDRAM
Memory clock speed	800 MHz

Storage

Specification	Value
Total storage capacity	500 GB
Optical drive type	DVD Super Multi
HDD interface	SATA II
HDD speed	7200 RPM
Card reader integrated	No
Floppy drive installed	No

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card model	Intel® GMA X4500
Discrete graphics card memory	0 GB
Maximum graphics card memory	0.821 GB
Graphics card family	Intel

Performance

Specification	Value
Product type	PC

Network

Specification	Value
Ethernet LAN	Yes
Wi-Fi	No
Networking features	Gigabit

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	10
HDMI ports quantity	0
Ethernet LAN (RJ-45) ports	1
Headphone outputs	1
Microphone in	Yes
VGA (D-Sub) ports quantity	1
DVI port	Yes
PS/2 ports quantity	2
Firewire (IEEE 1394) ports	0
eSATA ports quantity	1
Serial ports quantity	1
Parallel ports quantity	0

Expansion slots

Specification	Value
Expansion slots	1x PCI Express 2.0 x16 1x PCI Express 2.0 x1

Power

Specification	Value
Power supply	220 W

Design

Specification	Value
Chassis type	SFF
Cable lock slot	Yes
Cable lock slot type	Kensington

Software

Specification	Value
Operating system installed	Windows 7 Professional
Optional operating system supplied	Windows XP Professional
Bundled software	- Acer eRecovery Management - Veriton ControlCenter (Acer eLock Management, Acer eSettings Management, QuickMigration, PowerSaver, SmartBoot, HelpDesk) - Acer Client Manager - Acer Security Suite - Microsoft Office 2007 Ready - Adobe Reader - CyberLink PowerDVD - NTI Media Maker

Display

Specification	Value
Display included	No

Processor special features

Specification	Value
CPU configuration (max)	1
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Clear Video Technology	No
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	No
Intel Enhanced Halt State	Yes
Intel FDI Technology	No
Intel Fast Memory Access	No
Intel Flex Memory Access	No
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	No
Intel Virtualization Technology (VT-x)	2
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® Wireless Display (Intel® WiDi)	No
Processor ARK ID	40478
Processor code	SLGH7
Processor package size	37.5 x 37.5 mm
Thermal Monitoring Technologies	Yes
Intel® Turbo Boost Technology	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Quick Sync Video Technology	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Conflict-Free processor	No

Weight & dimensions

Specification	Value
Width	101.5 mm
Depth	396.8 mm
Height	266.5 mm

Packaging content

Specification	Value
Remote control included	No

Other features

Specification	Value
TV tuner integrated	No
Intel segment tagging	Enterprise, Small Business
