P330 F6 SE
Model P330 F6 SEPart no. US.RV9TL.001EAN 4711474612298
77 specifications
- ProcessorIntel Xeon W
- Memory128 GB
- Storage2 TB
- GraphicsNVIDIA GeForce RTX 5090
- TypeWorkstation
- OSNo
Overview
- Processor
- Intel Xeon W
- Memory
- 128 GB
- Storage
- 2 TB
- Graphics
- NVIDIA GeForce RTX 5090
- Type
- Workstation
- OS
- No
- Brand
- Acer
- Category
- PCs/Workstations
- Model
- P330 F6 SE
- Part number
- US.RV9TL.001
- EAN / UPC
- 4711474612298
- Also known as
- Acer Altos BrainSphere P330 F6 SE Intel Xeon W w3-2435 128 GB DDR5-SDRAM 2 TB SSD NVIDIA GeForce RTX 5090 Tower Workstation Black
Specifications
77 specifications in 16 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Xeon W |
| Processor model | w3-2435 |
| Processor cores | 8 |
| Processor threads | 16 |
| Processor boost frequency | 4.5 GHz |
| Processor frequency | 3.1 GHz |
| Performance cores | 8 |
| Efficient cores | 0 |
| Processor cache | 22.5 MB |
| Processor cache type | Smart Cache |
| Number of processors installed | 1 |
| Maximum turbo power | 198 W |
| Processor base power | 165 W |
Memory
| Specification | Value |
|---|---|
| Internal memory | 128 GB |
| Maximum internal memory | 512 GB |
| Internal memory type | DDR5-SDRAM |
| Memory slots | 8x DIMM |
| Memory clock speed | 4800 MHz |
| Buffered memory type | Registered (buffered) |
| ECC | Yes |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 2 TB |
| Optical drive type | No |
| Storage media | SSD |
| Total SSDs capacity | 2 TB |
| Number of SSDs installed | 1 |
| SSD capacity | 2 TB |
| NVMe | Yes |
| SSD interface | PCI Express |
| SSD form factor | M.2 |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | Yes |
| On-board graphics card | No |
| Discrete GPU manufacturer | NVIDIA |
| Discrete graphics card model | NVIDIA GeForce RTX 5090 |
| Discrete graphics card memory | 32 GB |
| Discrete graphics memory type | GDDR7 |
| Number of discrete graphics cards | 1 |
| On-board graphics card model | Not available |
| Graphics card DisplayPorts quantity | 3 |
| Graphics card HDMI ports quantity | 1 |
Performance
| Specification | Value |
|---|---|
| Product type | Workstation |
| Motherboard chipset | Intel W790 |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Audio output channels | 7.1 channels |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
| Thunderbolt 3 ports quantity | 0 |
| Ethernet LAN (RJ-45) ports | 2 |
| Headphone outputs | 1 |
| Line-out | Yes |
| Line-in | Yes |
| Microphone in | Yes |
| Number of SATA III connectors | 8 |
Expansion slots
| Specification | Value |
|---|---|
| Number of 3.5" bays | 4 |
| PCI Express x16 (Gen 5.x) slots | 5 |
Power
| Specification | Value |
|---|---|
| Power supply | 2000 W |
Design
| Specification | Value |
|---|---|
| Chassis type | Tower |
| Volume | 56 L |
| Placement supported | Vertical |
| Number of 5.25" bays | 1 |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Product colour | Black |
Software
| Specification | Value |
|---|---|
| Operating system installed | No |
Display
| Specification | Value |
|---|---|
| Display included | No |
Audio
| Specification | Value |
|---|---|
| Audio chip | Realtek ALC1220 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 230 mm |
| Depth | 470 mm |
| Height | 518.5 mm |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | BSMI, CB, CE, Federal Communications Commission (FCC) |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
