Acer Aspire X3900 One Box

Model Aspire X3900 One BoxPart no. PV.SD1E2.011EAN 4718235698270

123 specifications

Display50.8 cm (20")
ProcessorIntel® Core™ i3
Memory4 GB
Storage750 GB
GraphicsAMD Radeon HD 5450
TypePC

See all specifications

Overview

Display: 50.8 cm (20")
Processor: Intel® Core™ i3
Memory: 4 GB
Storage: 750 GB
Graphics: AMD Radeon HD 5450
Type: PC

Brand: Acer
Category: PCs/Workstations
Model: Aspire X3900 One Box
Part number: PV.SD1E2.011
EAN / UPC: 4718235698270
Also known as: Acer Aspire X3900 One Box Intel® Core™ i3 i3-530 4 GB DDR3-SDRAM 750 GB AMD Radeon HD 5450 Windows 7 Home Premium Small Desktop PC Black

Specifications

123 specifications in 17 groups

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i3
Processor generation	Intel® Core™ i3
Processor model	i3-530
Processor cores	2
Processor threads	4
Processor frequency	2.93 GHz
Processor cache	4 MB
Processor cache type	Smart Cache
Bus type	DMI
FSB Parity	No
System bus rate	2.5 GT/s
Processor lithography	32 nm
Processor operating modes	64-bit
Processor series	Intel Core i3-500 Desktop Series
Processor codename	Clarkdale
Thermal Design Power (TDP)	73 W
Tcase	72.6 °C
Maximum number of PCI Express lanes	16
PCI Express configurations	1x16, 2x8
PCI Express slots version	2.0
Processor socket	LGA 1156 (Socket H)
Number of Processing Die Transistors	382 M
Processing Die size	81 mm²
CPU multiplier (bus/core ratio)	22
Stepping	C2
Maximum internal memory supported by processor	16 GB
Memory types supported by processor	DDR3 1066/1333
Memory bandwidth supported by processor (max)	21 GB/s
ECC supported by processor	No

Memory

Specification	Value
Internal memory	4 GB
Maximum internal memory	8 GB
Internal memory type	DDR3-SDRAM
Memory layout (slots x size)	2 x 2 GB
Memory clock speed	1333 MHz
Memory channels	Dual-channel

Storage

Specification	Value
Total storage capacity	750 GB
Optical drive type	DVD Super Multi
HDD interface	SATA
HDD speed	7200 RPM
Card reader integrated	Yes
Floppy drive installed	No

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card model	AMD Radeon HD 5450
Discrete graphics card memory	0.512 GB
On-board graphics card family	Intel® HD Graphics
On-board graphics card model	Intel® HD Graphics
Number of displays supported (on-board graphics)	2
On-board graphics card base frequency	733 MHz
Maximum graphics card memory	1.738 GB

Performance

Specification	Value
Product type	PC
Motherboard chipset	Intel® H57 Express
Audio output channels	5.1 channels

Network

Specification	Value
Ethernet LAN	Yes
Wi-Fi	No
Networking features	Gigabit Ethernet

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	9
HDMI ports quantity	1
Ethernet LAN (RJ-45) ports	1
Headphone outputs	1
Microphone in	Yes
VGA (D-Sub) ports quantity	1
DVI port	No
PS/2 ports quantity	2
Firewire (IEEE 1394) ports	1
eSATA ports quantity	1
S/PDIF out port	Yes
Serial ports quantity	0
Parallel ports quantity	0

Expansion slots

Specification	Value
PCI Express x1 slots	1
PCI Express x16 slots	1

Power

Specification	Value
Power supply	220 W

Design

Specification	Value
Chassis type	Small Desktop
Product colour	Black

Software

Specification	Value
Operating system installed	Windows 7 Home Premium
Mac compatibility	No
Trial software	- Microsoft Works + Office Home & Student 2007 - McAfee Internet Security Suite 2009
Bundled software	- Acer eRecovery Management - Acer Arcade Deluxe - Adobe Reader - eSobi - MyWinLocker - Nero 9 Essentials - Oberon GameZone

Display

Specification	Value
Display included	Yes
Display diagonal	50.8 cm (20")

Processor special features

Specification	Value
CPU configuration (max)	1
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Graphics & IMC lithography	45 nm
Idle States	Yes
Intel 64	Yes
Intel Clear Video Technology	No
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	Yes
Intel Enhanced Halt State	Yes
Intel FDI Technology	Yes
Intel Fast Memory Access	No
Intel Flex Memory Access	No
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® Wireless Display (Intel® WiDi)	No
Physical Address Extension (PAE)	36 bit
Processor ARK ID	46472
Processor package size	37.5 x 37.5 mm
Supported instruction sets	SSE4.2
Thermal Monitoring Technologies	No
Intel® Turbo Boost Technology	No
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Quick Sync Video Technology	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Conflict-Free processor	No

Audio

Specification	Value
Audio system	High Definition Audio

Weight & dimensions

Specification	Value
Width	100 mm
Depth	352 mm
Height	265 mm

Packaging content

Specification	Value
Mouse included	Yes
Remote control included	No

Other features

Specification	Value
TV tuner integrated	No
