Acer Aspire X1301

Model Aspire X1301Part no. 98.XUM7A.E1NEAN 4718235929282

118 specifications

Display48.3 cm (19")
ProcessorIntel Pentium G
Memory3 GB
Storage320 GB
GraphicsNVIDIA® GeForce® 7100
TypePC

See all specifications

Overview

Display: 48.3 cm (19")
Processor: Intel Pentium G
Memory: 3 GB
Storage: 320 GB
Graphics: NVIDIA® GeForce® 7100
Type: PC

Brand: Acer
Category: PCs/Workstations
Model: Aspire X1301
Part numbers: 98.XUM7A.E1N, 98.X5M7G.DYN, 9P.XCM7Z.U7N, 98.XCF7A.DPN, 98.X5F7A.DYN
EAN / UPC: 4718235929282, 4718235925185, 4718235933555, 4718235937157
Also known as: Acer Aspire X1301 Intel Pentium G 620 3 GB DDR2-SDRAM 320 GB NVIDIA® GeForce® 7100 Windows 7 Home Premium Desktop PC Black

Specifications

118 specifications in 17 groups

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Pentium G
Processor model	620
Processor cores	2
Processor threads	2
Processor frequency	2.6 GHz
Processor cache	3 MB
Processor cache type	Smart Cache
Bus type	DMI
FSB Parity	No
System bus rate	5 GT/s
Processor lithography	32 nm
Processor operating modes	64-bit
Processor series	Intel Pentium G600 Series for Desktop
Processor codename	Sandy Bridge
Thermal Design Power (TDP)	65 W
Tcase	69.1 °C
PCI Express slots version	2.0
Processor socket	LGA 1155 (Socket H2)
Number of Processing Die Transistors	169 M
Processing Die size	135 mm²
CPU multiplier (bus/core ratio)	26
Stepping	N0
Maximum internal memory supported by processor	32 GB
Memory types supported by processor	DDR3 1066
Memory bandwidth supported by processor (max)	17 GB/s
ECC supported by processor	No

Memory

Specification	Value
Internal memory	3 GB
Maximum internal memory	4 GB
Internal memory type	DDR2-SDRAM
Memory slots	2x DIMM
Memory channels	Double-channel

Storage

Specification	Value
Total storage capacity	320 GB
Optical drive type	DVD-RW
HDD interface	SATA
Card reader integrated	Yes
Compatible memory cards	CF+, MMC, MS Pro, SD
Floppy drive installed	No

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card model	NVIDIA® GeForce® 7100
On-board graphics card family	Intel® HD Graphics
On-board graphics card model	Intel® HD Graphics
Number of displays supported (on-board graphics)	2
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Maximum graphics card memory	1.024 GB
Graphics card family	Nvidia

Performance

Specification	Value
Product type	PC
Audio output channels	5.1 channels

Network

Specification	Value
Ethernet LAN	Yes
Wi-Fi	No
Networking features	Gigabit Ethernet

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	9
HDMI ports quantity	1
Ethernet LAN (RJ-45) ports	1
Headphone outputs	1
Microphone in	Yes
VGA (D-Sub) ports quantity	1
DVI port	No
PS/2 ports quantity	2
Firewire (IEEE 1394) ports	1
eSATA ports quantity	1
DC-in jack	Yes
Serial ports quantity	0
Parallel ports quantity	0
Audio input	5

Expansion slots

Specification	Value
PCI Express x1 slots	1
PCI Express x16 slots	1

Design

Specification	Value
Chassis type	Desktop
Product colour	Black

Software

Specification	Value
Operating system installed	Windows 7 Home Premium
Drivers included	Yes
Trial software	McAfee Internet Security Suite 2009
Bundled software	Nero 9 Essentials Adobe Reader CyberLink PowerDVD

Display

Specification	Value
Display included	Yes
Display diagonal	48.3 cm (19")

Processor special features

Specification	Value
CPU configuration (max)	1
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Intel 64	Yes
Intel Clear Video Technology	No
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	Yes
Intel Enhanced Halt State	Yes
Intel FDI Technology	Yes
Intel Fast Memory Access	Yes
Intel Flex Memory Access	Yes
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	1
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® Wireless Display (Intel® WiDi)	No
Processor ARK ID	53480
Processor code	SL8AB
Processor package size	37.5 mm
Supported instruction sets	SSE4.1/4.2
Thermal Monitoring Technologies	Yes
Intel® Turbo Boost Technology	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Quick Sync Video Technology	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Conflict-Free processor	No

Audio

Specification	Value
Audio system	HD

Weight & dimensions

Specification	Value
Width	100 mm
Depth	352 mm
Height	265 mm

Packaging content

Specification	Value
Mouse included	Yes
Remote control included	No

Certificates

Specification	Value
Certification	FCC, CE, BSMI, CCC, VCCI, CB

Other features

Specification	Value
TV tuner integrated	No
