Acer Veriton N 282G-UD5253W Intel Atom® D525 2 GB DDR3-SDRAM 500 GB NVIDIA® ION™ 2 Windows 7 Professional USFF Mini PC Black, Grey

Model 282G-UD5253WPart no. DT.VBHAA.001EAN 886541537164

119 specifications

ProcessorIntel Atom®
Memory2 GB
Storage500 GB
GraphicsNVIDIA® ION™ 2
SpeedWi-Fi 4 (802.11n)
TypeMini PC

See all specifications

Overview

Processor: Intel Atom®
Memory: 2 GB
Storage: 500 GB
Graphics: NVIDIA® ION™ 2
Speed: Wi-Fi 4 (802.11n)
Type: Mini PC

Brand: Acer
Category: PCs/Workstations
Model: 282G-UD5253W
Part number: DT.VBHAA.001
EAN / UPC: 886541537164
Also known as: Acer Veriton N 282G-UD5253W Intel Atom® D525 2 GB DDR3-SDRAM 500 GB NVIDIA® ION™ 2 Windows 7 Professional USFF Mini PC Black, Grey

Specifications

119 specifications in 18 groups

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Atom®
Processor model	D525
Processor cores	2
Processor threads	4
Processor frequency	1.8 GHz
Processor cache	1 MB
Processor cache type	L2
Bus type	DMI
FSB Parity	No
Processor lithography	45 nm
Processor operating modes	64-bit
Processor series	Intel Atom D500 Series
Processor codename	Pineview
Thermal Design Power (TDP)	13 W
Tjunction	100 °C
Number of processors installed	1
Processor socket	BGA 559
Number of Processing Die Transistors	176 M
Processing Die size	87 mm²
Stepping	B0
Maximum internal memory supported by processor	4 GB
Memory types supported by processor	DDR3 800 (SODIMM only); DDR2 667/800
Memory bandwidth supported by processor (max)	6.4 GB/s
ECC supported by processor	No

Memory

Specification	Value
Internal memory	2 GB
Maximum internal memory	4 GB
Internal memory type	DDR3-SDRAM
Memory slots	2x SO-DIMM
Memory clock speed	1333 MHz
Memory channels	Single-channel

Storage

Specification	Value
Total storage capacity	500 GB
Optical drive type	No
Number of HDDs installed	1
HDD capacity	500 GB
HDD interface	SATA
HDD speed	5400 RPM
Number of SSDs installed	0
Card reader integrated	Yes

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card model	NVIDIA® ION™ 2
On-board graphics card model	Integrated
Graphics card family	Intel, NVIDIA

Performance

Specification	Value
Product type	Mini PC
Motherboard chipset	Intel NM10

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Wi-Fi	Yes
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Wi-Fi standards	802.11a, 802.11b, 802.11g
Ethernet interface type	Gigabit Ethernet
Networking features	Gigabit Ethernet
Wireless technology	Wi-Fi

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	6
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
HDMI ports quantity	1
Ethernet LAN (RJ-45) ports	1
Headphone outputs	1
Microphone in	Yes
VGA (D-Sub) ports quantity	1
DVI port	No
PS/2 ports quantity	0
Firewire (IEEE 1394) ports	0
Serial ports quantity	0
Parallel ports quantity	0
HDMI	Yes

Expansion slots

Specification	Value
Mini PCI Express slots	1

Power

Specification	Value
Power supply	65 W

Design

Specification	Value
Chassis type	USFF
Product colour	Black, Grey

Software

Specification	Value
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit
Optional operating system supplied	Windows XP Professional
Bundled software	Microsoft Office Starter, Bing Bar, Windows Live Essentials

Display

Specification	Value
Display included	No

Processor special features

Specification	Value
Embedded options available	Yes
Enhanced Intel SpeedStep Technology	No
Execute Disable Bit	Yes
Idle States	No
Intel 64	Yes
Intel Clear Video Technology	No
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	No
Intel Enhanced Halt State	No
Intel FDI Technology	No
Intel Fast Memory Access	No
Intel Flex Memory Access	No
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	No
Intel Virtualization Technology (VT-x)	No
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® Wireless Display (Intel® WiDi)	No
Physical Address Extension (PAE)	32 bit
Processor ARK ID	49490
Processor code	SLBXC
Processor package size	22 x 22 mm
Supported instruction sets	SSE2, SSE3, SSSE3
Thermal Monitoring Technologies	No
Intel® Turbo Boost Technology	No
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Quick Sync Video Technology	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Conflict-Free processor	No

Weight & dimensions

Specification	Value
Width	35.5 mm
Depth	193 mm
Height	193 mm

Packaging content

Specification	Value
Mouse included	Yes
Keyboard included	Yes

Certificates

Specification	Value
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR

Other features

Specification	Value
Intel segment tagging	Enterprise, Small Business
