Shuttle XPС slim XH310V PC/workstation barebone

Shuttle XPС slim XH310V PC/workstation barebone

3.5L sized PC Black Intel® H310 LGA 1151 (Socket H4)

Model XH310VEAN 887993001562

67 specifications
  • TypePC barebone
  • OSNo
  • Weight2.2 kg
  • ColourBlack
  • Memory slots typeSO-DIMM
  • Supported storage drive typesHDD & SSD
See all specifications

Overview

Type
PC barebone
OS
No
Weight
2.2 kg
Colour
Black
Memory slots type
SO-DIMM
Supported storage drive types
HDD & SSD
Brand
Shuttle
Model
XH310V
Part number
XH310V
EAN / UPC
887993001562
Also known as
Shuttle XPС slim XH310V PC/workstation barebone 3.5L sized PC Black Intel® H310 LGA 1151 (Socket H4)

Specifications

67 specifications in 16 groups

Processor

Built-in processorNo

Memory

Memory slots typeSO-DIMM
Number of memory slots2
Maximum internal memory32 GB
Memory channelsDual-channel
Memory voltage1.2 V
Supported memory clock speeds2400,2666 MHz
Supported memory typesDDR4-SDRAM
Non-ECCYes

Storage

Supported storage drive typesHDD & SSD
Storage drive sizes supported2.5,M.2
Number of storage drives supported3

Graphics

On-board graphics cardNo
Graphics card familyIntel

Performance

Motherboard form factormini ITX
Motherboard chipsetIntel® H310
Processor socketLGA 1151 (Socket H4)
Number of processors supported1
Compatible processor seriesIntel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Pentium®
Audio output channels5.1 channels
Audio chipRealtek ALC662

Network

Ethernet LANYes
Wi-FiNo

Ports & interfaces

USB 2.0 ports quantity4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
HDMI ports quantity1
HDMI version2.0a
VGA (D-Sub) ports quantity1
DisplayPorts quantity1
Microphone inYes
Headphone outputs1
Ethernet LAN (RJ-45) ports2
Serial ports quantity2
DC-in jackYes

Expansion slots

Number of M.2 (M) slots1

Design

Chassis type3.5L sized PC
Product colourBlack
Cooling typeActive
LED indicatorsHDD, Power
Cable lock slotYes
Cable lock slot typeKensington
Product typePC barebone
Market positioningBusiness
SafetyETL, CB, BSM

Sustainability

Sustainability certificatesENERGY STAR

Software

Windows operating systems supportedWindows 10
Linux operating systems supportedYes
Operating system installedNo

Certificates

CertificationFCC, CE, BSMI, C-Tick

Power

Power supply typeExternal AC adapter
AC adapter output current4.74 A
AC adapter output voltage19 V
AC input frequency50 - 60 Hz
AC input voltage100 - 240 V
Number of power supply units1
Power supply90 W

Operational conditions

Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)0 - 50 °C

Weight & dimensions

Width242 mm
Depth200 mm
Height72.5 mm
Weight2.2 kg
Package weight3.5 kg

Packaging content

Power cord includedYes
AC adapter includedYes
Quick start guideYes
Drivers includedYes
