PRO DP80 A14G i5 14400 BB
Model PRO DP80 A14G i5 14400 BBPart no. PRO DP80 A14G I5 14400 BBEAN 4711377366601
189 specifications
- ProcessorIntel® Core™ i5
- SpeedWi-Fi 6E (802.11ax)
- TypePC barebone
- ColourBlack
- Built-in processorYes
- Memory slots typeDIMM
Overview
- Processor
- Intel® Core™ i5
- Speed
- Wi-Fi 6E (802.11ax)
- Type
- PC barebone
- Colour
- Black
- Built-in processor
- Yes
- Memory slots type
- DIMM
- Brand
- MSI
- Category
- PC/Workstation Barebones
- Model
- PRO DP80 A14G i5 14400 BB
- Part number
- PRO DP80 A14G I5 14400 BB
- EAN / UPC
- 4711377366601
- Also known as
- MSI PRO DP80 A14G Intel Core 5 14400, Barebone, DP80 A14G, SFF, Mini Computer, HTPC, (NO RAM, NO Storage, NO OS), Intel Graphics/DDR5/Dual HDMI/Dual LAN/WiFi 6E
Specifications
189 specifications in 19 groups
Processor
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i5 |
| Processor cores | 10 |
| Processor threads | 16 |
| Processor boost frequency | 4.7 GHz |
| Processor frequency | 2.5 GHz |
| Performance cores | 6 |
| Efficient cores | 4 |
| Performance-core Max Turbo Frequency | 4.7 GHz |
| Efficient-core Max Turbo Frequency | 3.5 GHz |
| Performance-core base frequency | 2.5 GHz |
| Efficient-core base frequency | 1.8 GHz |
| Processor lithography | 10 nm |
| Processor cache | 20 MB |
| L2 cache | 9.5 MB |
| L3 cache | 20 MB |
| Thermal Design Power (TDP) | 65 W |
Memory
| Specification | Value |
|---|---|
| Memory slots type | DIMM |
| Number of memory slots | 2 |
| Maximum internal memory | 0 GB |
| Memory bandwidth (max) | 64 GB/s |
Storage
| Specification | Value |
|---|---|
| Supported storage drive types | SSD |
| Storage drive sizes supported | 2.5,3.5,M.2 |
| SSD form factor | M.2 |
| Number of storage drives supported | 0 |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | No |
Performance
| Specification | Value |
|---|---|
| Motherboard form factor | micro ATX |
| Motherboard chipset | Intel H610 |
| Processor socket | LGA 1700 |
| Number of processors supported | 1 |
| Compatible processor series | Intel Core i5 14th Gen |
| Supported processor frequency (max) | 5.4 GHz |
| BIOS type | UEFI |
| ACPI version | 5.0 |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Audio output channels | 7.1 channels |
| Audio chip | Realtek ALC897 |
| Consumer infrared Rx sensor | No |
Audio
| Specification | Value |
|---|---|
| Built-in speaker(s) | No |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| LAN controller | Intel® I219-V, Intel I226-V |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Internal USB 2.0 ports quantity | 4 |
| Internal USB 3.2 Gen 1 (3.1 Gen 1) ports quantity | 4 |
| USB4 Gen 2x2 ports quantity | 0 |
| USB4 Gen 3x2 ports quantity | 0 |
| HDMI ports quantity | 1 |
| Mini HDMI ports quantity | 0 |
| HDMI version | 2.1 |
| VGA (D-Sub) ports quantity | 1 |
| DVI port | No |
| DVI-D ports quantity | 0 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.4 |
| Mini DisplayPorts quantity | 0 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| Combo headphone/mic port | No |
| COM ports quantity | 1 |
| CardBus PCMCIA slot type | No |
| CardBus PCMCIA slots quantity | 0 |
| Consumer infrared headers | No |
| Ethernet LAN (RJ-45) ports | 2 |
| Firewire (IEEE 1394) ports | 0 |
| Number of SATA III connectors | 0 |
| PS/2 ports quantity | 1 |
| Parallel ports quantity | 0 |
| S/PDIF out port | No |
| Serial port via internal header | Yes |
| Serial ports quantity | 1 |
| TV-out | No |
| Thunderbolt 3 ports quantity | 0 |
| Thunderbolt 4 ports quantity | 0 |
| Thunderbolt ports quantity | 0 |
| USB charging | No |
| eSATA ports quantity | 0 |
| DC-in jack | No |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express slots version | 4.0 |
| PCI Express x1 slots | 1 |
| PCI Express x4 slots | 0 |
| PCI Express x4 (Gen 2.x) slots | 0 |
| PCI Express x8 slots | 0 |
| PCI Express x16 slots | 1 |
| PCI Express x16 (Gen 5.x) slots | 0 |
| PCI slots | 0 |
| Mini PCI Express slots | 0 |
| Mini PCI Express slot (half-length) | 0 |
| Mini PCI Express slot (full length) | 0 |
| PCI-X slots | 0 |
| Number of M.2 (M) slots | 1 |
Design
| Specification | Value |
|---|---|
| Chassis type | Mini-Tower |
| Product colour | Black |
| Cooling type | Active |
| On/off switch | Yes |
| Housing material | Metal, Plastic |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Product type | PC barebone |
Processor special features
| Specification | Value |
|---|---|
| Intel® vPro™ Platform Eligibility | No |
| Conflict-Free | Yes |
| Embedded options available | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Intel 64 | Yes |
| Intel Advanced Management Technology | No |
| Intel Clear Video Technology | Yes |
| Intel Demand Based Switching | Yes |
| Intel Dual Display Capable Technology | Yes |
| Intel Express BIOS update | Yes |
| Intel FDI Technology | Yes |
| Intel Fast Memory Access | Yes |
| Intel Flex Memory Access | Yes |
| Intel On-Demand Power Redundancy Technology | No |
| Intel Rapid Storage Technology | Yes |
| Intel Smart Connect Technology | No |
| Intel Stable Image Platform Program (SIPP) | No |
| Intel TSX-NI | No |
| Intel Trusted Execution Technology | No |
| Intel Unite installed | No |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Visual BIOS | No |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Anti-Theft Technology (Intel® AT) | No |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® High Definition Audio (Intel® HD Audio) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Insider™ | Yes |
| Intel® Matrix Storage Technology (Intel® MST) | No |
| Intel® My WiFi Technology (Intel® MWT) | No |
| Intel® OS Guard | Yes |
| Intel® Optane™ Memory Ready | Yes |
| Intel® Platform Trust Technology (Intel® PTT) | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® Rapid Start Technology | No |
| Intel® Secure Key | Yes |
| Intel® Small Business Advantage (Intel® SBA) | No |
| Intel® Smart Cache | Yes |
| Intel® Smart Response Technology | Yes |
| Intel® Turbo Boost Technology | Yes |
| Intel® Unite™ | No |
| Intel® Wireless Display (Intel® WiDi) | No |
| Thermal Monitoring Technologies | Yes |
Certificates
| Specification | Value |
|---|---|
| Waste Electrical and Electronic Equipment (WEEE) compliance | Yes |
Technical details
| Specification | Value |
|---|---|
| Not classified as hazardous under GHS | Yes |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | No |
| Linux operating systems supported | No |
Power
| Specification | Value |
|---|---|
| Power supply type | Internal power supply unit |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Number of power supply units | 1 |
| Power supply | 300 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 0 - 85% |
| Operating temperature (T-T) | 0 - 35 °C |
| Storage relative humidity (H-H) | 0 - 90% |
| Storage temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 95 mm |
| Depth | 296 mm |
| Height | 330 mm |
| Package width | 561 mm |
| Package depth | 234 mm |
| Package height | 372 mm |
Packaging content
| Specification | Value |
|---|---|
| Power cord included | Yes |
| AC adapter included | Yes |
| Quick start guide | Yes |
| Drivers included | No |
| Display included | No |
| Mouse included | No |
| Keyboard included | No |
Other features
| Specification | Value |
|---|---|
| Country of origin | China |
| Introduction month | June |
| Introduction year | 2025 |
| Warranty period | 3 year(s) |
