All-In-One Barebone X50N
Shuttle

All-In-One Barebone X50N

15.6" Single-Touch-Screen (resistive), Intel N150 , Wifi, IP54, fanless, 24/7 permanent operation

Model X50NPart no. X50N (BLACK)EAN 887993008592

91 specifications
  • Display39.6 cm (15.6")
  • Resolution1366 x 768 pixels
  • ProcessorN150
  • SpeedWi-Fi 5 (802.11ac)
  • TypeAll-in-One PC barebone
  • Weight3.26 kg
See all specifications

Overview

Display
39.6 cm (15.6")
Resolution
1366 x 768 pixels
Processor
N150
Speed
Wi-Fi 5 (802.11ac)
Type
All-in-One PC barebone
Weight
3.26 kg
Brand
Shuttle
Model
X50N
Part numbers
X50N (BLACK), X50N (WHITE)
EAN / UPC
887993008592, 887993008622
Also known as
Shuttle All-In-One Barebone X50N, 15.6" Single-Touch-Screen (resistive), Intel N150 , Wifi, IP54, fanless, 24/7 permanent operation

Specifications

91 specifications in 16 groups

Processor

Built-in processorYes
Processor manufacturerIntel
Processor modelN150
Processor cores4
Processor threads4
Processor boost frequency3.6 GHz
Processor cache6 MB

Memory

Internal memory installedNo
Memory slots typeSO-DIMM
Number of memory slots1
Maximum internal memory16 GB
Memory channelsSingle-channel
Memory voltage1.1 V
Supported memory clock speeds4800 MHz
Supported memory typesDDR5-SDRAM
ECCNo
Non-ECCYes

Storage

Storage drives installedNo
Supported storage drive typesHDD & SSD
Storage drive sizes supported2.5,M.2
Storage drive interfaceM.2, Serial ATA III
NVMeYes

Graphics

On-board graphics cardYes
Graphics card familyIntel
On-board graphics card modelIntel® Graphics
Number of displays supported3

Performance

Motherboard chipsetIntel SoC
Processor socketBGA 1264
Number of processors supported1
BIOS typeAMI EEPROM
Trusted Platform Module (TPM)Yes
Trusted Platform Module (TPM) version2.0

Display

Display diagonal39.6 cm (15.6")
Display resolution1366 x 768 pixels
TouchscreenYes
HD typeHD
Aspect ratio16:9
Display brightness220 cd/m²

Audio

Built-in speaker(s)Yes
Number of speakers2
RMS rated power2 W

Network

Ethernet LANYes
Wi-FiYes
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
WLAN controller modelRealtek RTL8821CE
Copper ethernet cabling technology2.5GBASE-T
BluetoothYes
Bluetooth version4.2
LAN controllerIntel I226-LM

Ports & interfaces

USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity2
HDMI ports quantity1
HDMI version2.0b
VGA (D-Sub) ports quantity1
Microphone inYes
Headphone outputs1
Ethernet LAN (RJ-45) ports1
DC-in jackYes

Design

Chassis typeAll-in-One
Product colourBlack
Cooling typePassive
On/off switchYes
LED indicatorsHDD, Power
Cable lock slotYes
Cable lock slot typeKensington
VESA mountingYes
Panel mounting interface100 x 100 mm
Product typeAll-in-One PC barebone

Software

Windows operating systems supportedWindows 11
Linux operating systems supportedYes

Logistics data

Harmonized System (HS) code84714100

Power

Power supply typeExternal AC adapter
AC adapter output current3.42 A
AC adapter output voltage19 V
AC input frequency50/60 Hz
AC input voltage100 - 240 V
Number of power supply units1
Power supply65 W

Operational conditions

Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)0 - 40 °C

Weight & dimensions

Width391 mm
Depth42 mm
Height327 mm
Weight3.26 kg
Package weight4.5 kg

Packaging content

Power cord includedYes
AC adapter includedYes
Quick start guideYes
Drivers includedYes
