SX48P2 Deluxe (Prima Series)
Model SX48P2 Deluxe (Prima Series)Part no. SX48P2
28 specifications
- ProcessorIntel
- Weight6 kg
- ColourBlack
- Memory slots typeDIMM
- Processor socketLGA 775 (Socket T)
- USB 2.0 ports quantity8
Overview
- Processor
- Intel
- Weight
- 6 kg
- Colour
- Black
- Memory slots type
- DIMM
- Processor socket
- LGA 775 (Socket T)
- USB 2.0 ports quantity
- 8
- Brand
- Shuttle
- Category
- PC/Workstation Barebones
- Model
- SX48P2 Deluxe (Prima Series)
- Part number
- SX48P2
- Also known as
- Shuttle SX48P2 Deluxe (Prima Series) Mini-Tower Black LGA 775 (Socket T)
Specifications
28 specifications in 9 groups
Processor
| Specification | Value |
|---|---|
| Processor family | Intel |
Memory
| Specification | Value |
|---|---|
| Memory slots type | DIMM |
| Number of memory slots | 4 |
| Maximum internal memory | 8 GB |
Performance
| Specification | Value |
|---|---|
| Processor socket | LGA 775 (Socket T) |
| Compatible processor series | Intel® Pentium® D, Intel® Pentium® Dual-Core |
| Audio output channels | 7.1 channels |
| Audio system | HD Audio |
Network
| Specification | Value |
|---|---|
| Networking features | Gigabit Ethernet, Bluetooth 2.0, WLAN 802.11b/g |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 8 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| S/PDIF out port | Yes |
| eSATA ports quantity | 2 |
Design
| Specification | Value |
|---|---|
| Chassis type | Mini-Tower |
| Product colour | Black |
| Housing material | Aluminium |
Power
| Specification | Value |
|---|---|
| Power supply | 450 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 6 kg |
Other features
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 220 x 325 x 210 mm |
| Number of Parallel ATA connectors | 1 |
| Number of SATA connectors | 4 |
| Power requirements | 100-240V |
| Processor system buses supported | 1066,1333,1600 MHz |
| Special features | Fingerprint |
| Drive bays | 1x 5.25“, 3x 3.5“ |
| Expansion slots | 2x PCI-Express 2.0 (x16) 1x Mini-PCIe |
