Shuttle XPC cube Barebone SW580R8 - S1200, Intel W580, vPRO, 4x LAN (2x
Shuttle

XPC cube Barebone SW580R8 - S1200, Intel W580, vPRO, 4x LAN (2x

1Gb & 2x 2.5Gb), 4x 3.5" HDD bays

Model SW580R8EAN 887993004174

75 specifications
  • TypePC barebone
  • OSNo
  • Weight3.5 kg
  • ColourBlack
  • Memory slots typeDIMM
  • Supported storage drive typesHDD & SSD
See all specifications

Overview

Type
PC barebone
OS
No
Weight
3.5 kg
Colour
Black
Memory slots type
DIMM
Supported storage drive types
HDD & SSD
Brand
Shuttle
Model
SW580R8
Part number
SW580R8
EAN / UPC
887993004174, 887993005447
Also known as
Shuttle XPC cube Barebone SW580R8 - S1200, Intel W580, vPRO, 4x LAN (2x 1Gb & 2x 2.5Gb), 4x 3.5" HDD bays

Specifications

75 specifications in 17 groups

Processor

Built-in processorNo
Thermal Design Power (TDP)125 W

Memory

Memory slots typeDIMM
Number of memory slots4
Maximum internal memory128 GB
Memory channelsDual-channel
Memory voltage1.2 V
Supported memory clock speeds2666,2933,3200 MHz
Supported memory typesDDR4-SDRAM
ECCYes

Storage

Supported storage drive typesHDD & SSD
Storage drive sizes supported2.5,3.5,M.2
Storage drive interfaceSerial ATA III
Number of storage drives supported6
RAID levels0, 1, 5, 10, JBOD
Card reader integratedNo

Graphics

On-board graphics cardYes
Graphics card familyIntel
On-board graphics card modelIntel® UHD Graphics

Performance

Motherboard chipsetIntel W580
Processor socketLGA 1200 (Socket H5)
Number of processors supported1
Compatible processor seriesIntel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel Xeon W
BIOS typeUEFI AMI
Trusted Platform Module (TPM)Yes
Trusted Platform Module (TPM) version2.0
Audio output channels5.1 channels
Audio chipRealtek ALC897

Audio

Built-in speaker(s)No

Network

Ethernet LANYes
Wi-FiNo
LAN controllerIntel® I210-AT, Intel® I219-LM, Realtek RTL8125B

Ports & interfaces

USB 2.0 ports quantity4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity7
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity1
HDMI ports quantity1
HDMI version2.0b
DisplayPorts quantity1
DisplayPort version1.4
Microphone inYes
Headphone outputs2
Ethernet LAN (RJ-45) ports4

Expansion slots

PCI Express slots version3.0, 4.0
PCI Express x4 slots1
PCI Express x16 slots1
Number of M.2 (M) slots2

Design

Chassis typeCube
Product colourBlack
Cooling typeActive
On/off switchYes
LED indicatorsHDD, Power
Housing materialAluminium
Cable lock slotYes
Cable lock slot typeKensington
Product typePC barebone

Sustainability

Sustainability certificatesENERGY STAR, ErP

Technical details

Compliance certificatesCE, RoHS

Software

Windows operating systems supportedWindows 10, Windows 11
Linux operating systems supportedYes
Operating system installedNo

Power

Power supply typeInternal power supply unit
AC input frequency50 - 60 Hz
AC input voltage100 - 240 V
Number of power supply units1
Power supply500 W

Operational conditions

Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)0 - 40 °C

Weight & dimensions

Width215 mm
Depth332 mm
Height190 mm
Weight3.5 kg
Package weight4.5 kg

Packaging content

Power cord includedYes
Quick start guideYes
Drivers includedYes
