Shuttle SH97R6 PC/workstation barebone Black Intel® H97 LGA 1150 (Socket H3)
Model SH97R6EAN 811686006879
60 specifications
- TypePC barebone
- OSNo
- Weight3.5 kg
- ColourBlack
- Memory slots typeDIMM
- Storage drive sizes supported2.5,3.5"
Overview
- Type
- PC barebone
- OS
- No
- Weight
- 3.5 kg
- Colour
- Black
- Memory slots type
- DIMM
- Storage drive sizes supported
- 2.5,3.5"
- Brand
- Shuttle
- Category
- PC/Workstation Barebones
- Model
- SH97R6
- Part number
- SH97R6
- EAN / UPC
- 811686006879, 8116860068790
- Also known as
- Shuttle SH97R6 PC/workstation barebone Black Intel® H97 LGA 1150 (Socket H3)
Specifications
60 specifications in 17 groups
Processor
| Specification | Value |
|---|---|
| Built-in processor | No |
Memory
| Specification | Value |
|---|---|
| Memory slots type | DIMM |
| Number of memory slots | 4 |
| Maximum internal memory | 32 GB |
| Memory channels | Dual-channel |
| Supported memory clock speeds | 1333,1600 MHz |
| Supported memory types | DDR3-SDRAM |
Storage
| Specification | Value |
|---|---|
| Storage drive sizes supported | 2.5,3.5" |
| Storage drive interface | Serial ATA III |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | No |
| Graphics card family | Intel |
Performance
| Specification | Value |
|---|---|
| Motherboard chipset | Intel® H97 |
| Processor socket | LGA 1150 (Socket H3) |
| Number of processors supported | 1 |
| Compatible processor series | Intel® Celeron® G, Intel Pentium G |
| BIOS type | UEFI AMI |
| Audio output channels | 7.1 channels |
| Audio system | Realtek ALC892 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | No |
| LAN controller | Realtek RTL8111G |
| Networking features | Gigabit LAN |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 6 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 2 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| eSATA ports quantity | 1 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x4 slots | 1 |
| PCI Express x16 slots | 1 |
| Mini PCI Express slots | 2 |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Cooling type | Active |
| LED indicators | HDD |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Product type | PC barebone |
| Safety | ETL, CB, BSMI, TÜV |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
Software
| Specification | Value |
|---|---|
| Compatible operating systems | Windows 8 / 8.1, Windows 7, Linux |
| Operating system installed | No |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC, CE, BSMI, C-Tick, RoHS |
Power
| Specification | Value |
|---|---|
| Number of power supply units | 1 |
| Power supply | 300 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 35 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 216 mm |
| Depth | 332 mm |
| Height | 198 mm |
| Weight | 3.5 kg |
| Package weight | 5 kg |
Packaging content
| Specification | Value |
|---|---|
| Power cord included | Yes |
| Quick start guide | Yes |
| Drivers included | Yes |
Other features
| Specification | Value |
|---|---|
| Number of processors installed | 0 |
| Number of products included | 1 pc(s) |
| Power LED | Yes |
| Power requirements | 100 - 240V, 50/60Hz |
