Shuttle Edge PC SPCEL03
Shuttle

Edge PC SPCEL03

Model Edge PC SPCEL03Part no. SPCEL03EAN 887993007229

69 specifications
  • ProcessorIntel Atom®
  • TypeMini PC barebone
  • OSNo
  • Weight720 g
  • ColourBlack
  • Built-in processorYes
See all specifications

Overview

Processor
Intel Atom®
Type
Mini PC barebone
OS
No
Weight
720 g
Colour
Black
Built-in processor
Yes
Brand
Shuttle
Model
Edge PC SPCEL03
Part number
SPCEL03
EAN / UPC
887993007229
Also known as
Shuttle Edge PC SPCEL03 , Intel Atom x6413E, 1x HDMI, 2x 2.5G LAN, 1x COM, DIO (4x in, 4x out), 3x USB, 2x M.2, 12-24V, fanless, 24/7, -20... 60°C, incl. VESA &

Specifications

69 specifications in 17 groups

Processor

Built-in processorYes
Processor manufacturerIntel
Processor familyIntel Atom®
Processor modelx6413E
Processor cores4
Processor threads4
Processor boost frequency3 GHz
Processor frequency1.5 GHz
L2 cache1.5 MB
Thermal Design Power (TDP)9 W

Memory

Memory slots typeSO-DIMM
Number of memory slots1
Maximum internal memory32 GB
Memory channelsSingle-channel
Memory voltage1.2 V
Supported memory clock speeds3200 MHz
Supported memory typesDDR4-SDRAM
ECCNo
Non-ECCYes

Storage

Supported storage drive typesSSD
Storage drive sizes supportedM.2
SSD form factorM.2
Storage drive interfaceSerial ATA

Graphics

On-board graphics cardYes
Graphics card familyIntel
On-board graphics card modelIntel® UHD Graphics

Performance

Motherboard chipsetIntel SoC
Processor socketBGA 1493
Number of processors supported1
BIOS typeUEFI AMI
Trusted Platform Module (TPM)Yes
Trusted Platform Module (TPM) version2.0

Audio

Built-in speaker(s)No

Network

Ethernet LANYes
Wi-FiNo
LAN controllerIntel I226-V

Ports & interfaces

USB 2.0 ports quantity1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity2
HDMI ports quantity1
HDMI version2.0b
VGA (D-Sub) ports quantity0
Ethernet LAN (RJ-45) ports2
Serial ports quantity1
DC-in jackYes

Design

Chassis type0.46L sized PC
Product colourBlack
Cooling typePassive
LED indicatorsPower
Housing materialAluminium
VESA mountingYes
Panel mounting interface100 x 100 mm
Product typeMini PC barebone

Sustainability

Sustainability certificatesENERGY STAR

Technical details

Compliance certificatesCE, Federal Communications Commission (FCC), RoHS, VCCI

Software

Windows operating systems supportedWindows 10, Windows 11
Linux operating systems supportedYes
Operating system installedNo

Logistics data

Harmonized System (HS) code84733080

Power

Power supply typeExternal AC adapter
AC adapter output voltage12 - 24 V

Operational conditions

Operating relative humidity (H-H)20 - 80%
Operating temperature (T-T)-20 - 60 °C

Weight & dimensions

Width120 mm
Depth75 mm
Height51 mm
Weight720 g
Package weight1.2 kg

Packaging content

AC adapter includedNo
