Shuttle DS61 V1.1
Model DS61 V1.1Part no. DS61V1.1EAN 621562475923
31 specifications
- Memory8 GB
- ColourBlack
- Memory slots typeSO-DIMM
- Storage drive sizes supported2.5"
- Motherboard chipsetIntel® H61 Express
- Ethernet LANYes
Overview
- Memory
- 8 GB
- Colour
- Black
- Memory slots type
- SO-DIMM
- Storage drive sizes supported
- 2.5"
- Motherboard chipset
- Intel® H61 Express
- Ethernet LAN
- Yes
- Brand
- Shuttle
- Category
- PC/Workstation Barebones
- Model
- DS61 V1.1
- Part number
- DS61V1.1
- EAN / UPC
- 621562475923, 669626970229, 7123290471572, 8116860060534
- Also known as
- Shuttle DS61 V1.1 Black Intel® H61 Express
Specifications
31 specifications in 9 groups
Memory
| Specification | Value |
|---|---|
| Memory slots type | SO-DIMM |
| Number of memory slots | 2 |
| Internal memory | 8 GB |
| Maximum internal memory | 16 GB |
| Memory channels | Dual-channel |
| Supported memory clock speeds | 1333 MHz |
| Supported memory types | DDR3-SDRAM |
Storage
| Specification | Value |
|---|---|
| Storage drive sizes supported | 2.5" |
| Storage drive interface | Serial ATA II |
| Card reader integrated | Yes |
| Compatible memory cards | SD |
Performance
| Specification | Value |
|---|---|
| Motherboard chipset | Intel® H61 Express |
| Audio system | Realtek ALC662, High Definition Audio |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| LAN controller | Realtek 8111E X2 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| HDMI ports quantity | 1 |
| DVI port | Yes |
| Microphone in | Yes |
| Headphone outputs | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
Expansion slots
| Specification | Value |
|---|---|
| Mini PCI Express slots | 1 |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| LED indicators | HDD |
Power
| Specification | Value |
|---|---|
| Power supply | 90 W |
Other features
| Specification | Value |
|---|---|
| DC input voltage | 19 V |
| Dimensions (WxDxH) | 165 x 190 x 43 mm |
| Number of SATA connectors | 3 |
| Power LED | Yes |
