Shuttle XPС slim DS20U
Shuttle

XPС slim DS20U

1.3L sized PC Black 5205U Intel SoC 1.9 GHz

Model DS20UPart no. PEB-DS20U001EAN 887993003900

94 specifications
  • ProcessorIntel® Celeron®
  • TypeMini PC barebone
  • OSNo
  • Weight1.5 kg
  • ColourBlack
  • Built-in processorYes
See all specifications

Overview

Processor
Intel® Celeron®
Type
Mini PC barebone
OS
No
Weight
1.5 kg
Colour
Black
Built-in processor
Yes
Brand
Shuttle
Model
DS20U
Part number
PEB-DS20U001
EAN / UPC
887993003900
Also known as
Shuttle XPС slim DS20U 1.3L sized PC Black 5205U Intel SoC 1.9 GHz

Specifications

94 specifications in 18 groups

Processor

Built-in processorYes
Processor manufacturerIntel
Processor familyIntel® Celeron®
Processor model5205U
Processor cores2
Processor threads2
Processor frequency1.9 GHz
Processor lithography14 nm
Processor cache2 MB
Thermal Design Power (TDP)15 W
CPU configuration (max)1

Memory

Memory slots typeSO-DIMM
Number of memory slots2
Maximum internal memory64 GB
Memory channelsDual-channel
Memory voltage1.2 V
Supported memory clock speeds2400 MHz
Supported memory typesDDR4-SDRAM
Non-ECCYes

Storage

Supported storage drive typesHDD & SSD
Storage drive sizes supported2.5,M.2
Storage drive interfacePCI Express, Serial ATA III
Number of storage drives supported2
Card reader integratedYes
Compatible memory cardsSD, SDHC, SDXC

Graphics

On-board graphics cardYes
Graphics card familyIntel
On-board graphics card modelIntel® UHD Graphics

Performance

Motherboard chipsetIntel SoC
Number of processors supported1
BIOS typeUEFI AMI
Trusted Platform Module (TPM)Yes
Trusted Platform Module (TPM) version2.0

Audio

Built-in speaker(s)No

Network

Ethernet LANYes
Wi-FiNo
LAN controllerIntel® I211, Intel® I219-LM

Ports & interfaces

USB 2.0 ports quantity4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
HDMI ports quantity1
HDMI version2.0a
VGA (D-Sub) ports quantity1
DisplayPorts quantity1
DisplayPort version1.2
Microphone inYes
Headphone outputs1
Ethernet LAN (RJ-45) ports2
Serial ports quantity1
DC-in jackYes

Expansion slots

Number of M.2 (M) slots1

Design

Chassis type1.3L sized PC
Product colourBlack
Cooling typePassive
On/off switchYes
LED indicatorsHDD, Power
Cable lock slotYes
Cable lock slot typeKensington
VESA mountingYes
Product typeMini PC barebone

Processor special features

Embedded options availableNo
Enhanced Intel SpeedStep TechnologyYes
Execute Disable BitYes
Idle StatesYes
Intel 64Yes
Intel Clear Video TechnologyYes
Intel Flex Memory AccessYes
Intel TSX-NINo
Intel Trusted Execution TechnologyNo
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes

Software

Windows operating systems supportedWindows 10, Windows 11
Linux operating systems supportedYes
Operating system installedNo

Logistics data

Harmonized System (HS) code84713000

Power

Power supply typeExternal AC adapter
AC adapter output current3.42 A
AC adapter output voltage19 V
AC input frequency50 - 60 Hz
AC input voltage100 - 240 V
Number of power supply units1
Power supply65 W

Operational conditions

Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)0 - 40 °C

Weight & dimensions

Width165 mm
Depth200 mm
Height39.5 mm
Weight1.5 kg
Package weight2.2 kg

Packaging content

Power cord includedYes
AC adapter includedYes
Quick start guideYes
Drivers includedYes

Other features

Country of originChina
