Shuttle XPС slim DH270 PC/workstation barebone

1.3L sized PC Black Intel® H270 LGA 1151 (Socket H4)

Model DH270EAN 887993001319

70 specifications

Overview

Brand: Shuttle
Category: PC/Workstation Barebones
Model: DH270
Part number: DH270
EAN / UPC: 887993001319
Also known as: Shuttle XPС slim DH270 PC/workstation barebone 1.3L sized PC Black Intel® H270 LGA 1151 (Socket H4)

70 specifications in 15 groups

Specification	Value
Built-in processor	No

Specification	Value
Memory slots type	SO-DIMM
Number of memory slots	2
Maximum internal memory	32 GB
Memory channels	Dual-channel
Memory voltage	1.2 V
Supported memory clock speeds	2133,2400 MHz
Supported memory types	DDR4-SDRAM
ECC	No

Specification	Value
Supported storage drive types	HDD & SSD
Storage drive sizes supported	2.5"
Storage drive interface	Serial ATA III
Number of storage drives supported	1
Card reader integrated	Yes
Compatible memory cards	SD, SDHC, SDXC

Specification	Value
On-board graphics card	No

Specification	Value
Motherboard chipset	Intel® H270
Processor socket	LGA 1151 (Socket H4)
Number of processors supported	1
Compatible processor series	Intel® Celeron®, Intel® Pentium®
Audio output channels	2.0 channels
Audio system	HD

Specification	Value
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
HDMI ports quantity	3
HDMI version	1.4b/2.0
VGA (D-Sub) ports quantity	0
Microphone in	Yes
Headphone outputs	1
Ethernet LAN (RJ-45) ports	2
Serial ports quantity	2
DC-in jack	Yes

Specification	Value
Sustainability certificates	ENERGY STAR

Specification	Value
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64
Linux operating systems supported	Yes
Operating system installed	No

Specification	Value
Certification	FCC, CE, BSMI, C-Tick, RoHS, ErP

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 50 °C
