BoxPC BPCWL02 konfig Intel CPU
Model BoxPC BPCWL02 konfig Intel CPUPart no. BPCWL02EAN 887993004655
38 specifications
- TypeMini PC
- Weight2.85 kg
- ColourBlack, Blue
- Built-in processorNo
- Memory slots typeSO-DIMM
- Supported storage drive typesSSD
Overview
- Type
- Mini PC
- Weight
- 2.85 kg
- Colour
- Black, Blue
- Built-in processor
- No
- Memory slots type
- SO-DIMM
- Supported storage drive types
- SSD
- Brand
- Shuttle
- Category
- PC/Workstation Barebones
- Model
- BoxPC BPCWL02 konfig Intel CPU
- Part number
- BPCWL02
- EAN / UPC
- 887993004655
- Also known as
- Shuttle BoxPC BPCWL02 konfig Intel CPU Mini PC Black, Blue
Specifications
38 specifications in 12 groups
Processor
| Specification | Value |
|---|---|
| Built-in processor | No |
| Processor manufacturer | Intel |
Memory
| Specification | Value |
|---|---|
| Memory slots type | SO-DIMM |
| Number of memory slots | 2 |
| Maximum internal memory | 64 GB |
| Memory channels | Dual-channel |
| Supported memory clock speeds | 2400 MHz |
Storage
| Specification | Value |
|---|---|
| Supported storage drive types | SSD |
| Storage drive sizes supported | M.2 |
| SSD form factor | M.2 |
| Storage drive interface | Serial ATA |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | No |
| Number of displays supported | 3 |
Performance
| Specification | Value |
|---|---|
| Audio output channels | 2.0 channels |
| Audio chip | Realtek ALC662 |
Audio
| Specification | Value |
|---|---|
| Built-in speaker(s) | No |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| HDMI ports quantity | 2 |
| HDMI version | 1.4 |
| Microphone in | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
| Serial ports quantity | 3 |
Design
| Specification | Value |
|---|---|
| Chassis type | Mini PC |
| Product colour | Black, Blue |
| Cooling type | Passive |
| Housing material | Aluminium, Steel |
| VESA mounting | Yes |
| Product type | Mini PC |
Power
| Specification | Value |
|---|---|
| Power supply type | External AC adapter |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 20 - 80% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 245 mm |
| Depth | 57 mm |
| Height | 169 mm |
| Weight | 2.85 kg |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
