MSI ProBox23-001BEU-BXX Black Intel® H81 LGA 1150 (Socket H3)
Model ProBox23-001BEU-BXXPart no. ProBox23-001BEUEAN 4053162790018
36 specifications
- ProcessorIntel
- TypeMini PC barebone
- OSNo
- Weight1.15 kg
- ColourBlack
- Memory slots typeSO-DIMM
Overview
- Processor
- Intel
- Type
- Mini PC barebone
- OS
- No
- Weight
- 1.15 kg
- Colour
- Black
- Memory slots type
- SO-DIMM
- Brand
- MSI
- Category
- PC/Workstation Barebones
- Model
- ProBox23-001BEU-BXX
- Part number
- ProBox23-001BEU
- EAN / UPC
- 4053162790018, 4719072339739
- Also known as
- MSI ProBox23-001BEU-BXX Black Intel® H81 LGA 1150 (Socket H3)
Specifications
36 specifications in 13 groups
Processor
| Specification | Value |
|---|---|
| Built-in processor | No |
| Processor family | Intel |
Memory
| Specification | Value |
|---|---|
| Memory slots type | SO-DIMM |
| Number of memory slots | 2 |
| Maximum internal memory | 16 GB |
| Supported memory clock speeds | 1333 MHz |
| Supported memory types | DDR3-SDRAM |
Storage
| Specification | Value |
|---|---|
| Storage drive sizes supported | 2.5" |
| Storage drive interface | Serial ATA II |
| Number of storage drives supported | 2 |
Performance
| Specification | Value |
|---|---|
| Motherboard chipset | Intel® H81 |
| Processor socket | LGA 1150 (Socket H3) |
| Number of processors supported | 1 |
| Compatible processor series | Intel® Pentium® |
| Audio system | Realtek ALC887 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Networking features | Gigabit Ethernet |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 6 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| HDMI ports quantity | 1 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| eSATA ports quantity | 1 |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Cooling type | Active |
| Product type | Mini PC barebone |
| Safety | UL/CUL.TUV |
Software
| Specification | Value |
|---|---|
| Compatible operating systems | Windows 7 Home Premium/Professional 64 bit, Windows 8.1 |
| Operating system installed | No |
Certificates
| Specification | Value |
|---|---|
| Certification | EMC: BSMI, KCC, CE, FCC, C-TICK, CB, GOST |
Power
| Specification | Value |
|---|---|
| Power supply | 120 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Storage temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 1.15 kg |
Other features
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 202 x 204 x 54.8 mm |
