PRO DP180 A14-090BEU
Model PRO DP180 A14-090BEUEAN 4711377406567
79 specifications
- ProcessorIntel® Core™ i5
- Memory8 GB
- GraphicsNot available
- SpeedWi-Fi 5 (802.11ac)
- TypePC barebone
- Weight4.93 kg
Overview
- Processor
- Intel® Core™ i5
- Memory
- 8 GB
- Graphics
- Not available
- Speed
- Wi-Fi 5 (802.11ac)
- Type
- PC barebone
- Weight
- 4.93 kg
- Brand
- MSI
- Category
- PC/Workstation Barebones
- Model
- PRO DP180 A14-090BEU
- Part number
- PRO DP180 A14-090BEU
- EAN / UPC
- 4711377406567
- Also known as
- MSI PRO DP180 A14-090BEU PC/workstation barebone Desktop Black i5-14400 Intel H610 LGA 1700
Specifications
79 specifications in 14 groups
Processor
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i5 |
| Processor generation | Intel® Core™ i5 (14th gen) |
| Processor model | i5-14400 |
| Processor cores | 10 |
| Processor threads | 16 |
| Processor boost frequency | 4.7 GHz |
| Performance cores | 6 |
| Efficient cores | 4 |
| Performance-core Max Turbo Frequency | 4.7 GHz |
| Efficient-core Max Turbo Frequency | 3.5 GHz |
| Performance-core base frequency | 2.5 GHz |
| Efficient-core base frequency | 1.8 GHz |
| Processor cache | 20 MB |
| Processor cache type | Smart Cache |
Memory
| Specification | Value |
|---|---|
| Internal memory installed | No |
| Memory slots type | DIMM |
| Internal memory | 8 GB |
| Maximum internal memory | 64 GB |
Storage
| Specification | Value |
|---|---|
| Storage drives installed | No |
| Supported storage drive types | HDD & SSD |
| SSD form factor | M.2 |
| Card reader integrated | Yes |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| On-board graphics card model | Intel UHD Graphics 730 |
| Discrete graphics card model | Not available |
Performance
| Specification | Value |
|---|---|
| Motherboard chipset | Intel H610 |
| Processor socket | LGA 1700 |
| Optical drive type | No |
| Audio output channels | 7.1 channels |
| Audio chip | Realtek ALC897 |
Audio
| Specification | Value |
|---|---|
| Built-in speaker(s) | No |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | Wi-Fi 5 (802.11ac) |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
| LAN controller | Intel® I219-V |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| VGA (D-Sub) ports quantity | 1 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.4 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| Combo headphone/mic port | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| PS/2 ports quantity | 1 |
| Thunderbolt 3 ports quantity | 0 |
Design
| Specification | Value |
|---|---|
| Chassis type | Desktop |
| Product colour | Black |
| Cooling type | Active |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Product type | PC barebone |
| Number of 3.5" bays | 1 |
Power
| Specification | Value |
|---|---|
| Power supply type | External AC adapter |
| Power supply | 300 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 0 - 85% |
| Operating temperature (T-T) | 0 - 35 °C |
| Storage relative humidity (H-H) | 0 - 90% |
| Storage temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 168 mm |
| Depth | 335.1 mm |
| Height | 369.4 mm |
| Weight | 4.93 kg |
| Package width | 455 mm |
| Package depth | 240 mm |
| Package height | 485 mm |
| Package weight | 7.3 kg |
Packaging content
| Specification | Value |
|---|---|
| Display included | No |
Other features
| Specification | Value |
|---|---|
| Warranty period | 3 year(s) |
