PRO DP10 13M-009BE
Model PRO DP10 13M-009BEEAN 4711377063500
55 specifications
- ProcessorIntel® Core™ i7
- SpeedWi-Fi 6E (802.11ax)
- TypeMini PC barebone
- OSNo
- Weight1.1 kg
- ColourBlack
Overview
- Processor
- Intel® Core™ i7
- Speed
- Wi-Fi 6E (802.11ax)
- Type
- Mini PC barebone
- OS
- No
- Weight
- 1.1 kg
- Colour
- Black
- Brand
- MSI
- Category
- PC/Workstation Barebones
- Model
- PRO DP10 13M-009BE
- Part number
- PRO DP10 13M-009BE
- EAN / UPC
- 4711377063500
- Also known as
- MSI PRO DP10 13M-009BE PC/workstation barebone 1.1L sized PC Black i7-1360P Intel SoC
Specifications
55 specifications in 12 groups
Processor
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i7 |
| Processor generation | 13th gen Intel® Core™ i7 |
| Processor model | i7-1360P |
| Processor cores | 12 |
| Processor threads | 16 |
| Processor boost frequency | 5 GHz |
| Performance cores | 4 |
| Efficient cores | 8 |
| Processor cache | 18 MB |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory | 64 GB |
Storage
| Specification | Value |
|---|---|
| Supported storage drive types | HDD & SSD |
| Storage drive sizes supported | 2.5" |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| Graphics card family | Intel |
| On-board graphics card model | Intel UHD Graphics 770 |
Performance
| Specification | Value |
|---|---|
| Motherboard chipset | Intel SoC |
| Optical drive type | No |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| HDMI ports quantity | 1 |
| VGA (D-Sub) ports quantity | 0 |
| DisplayPorts quantity | 1 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| Combo headphone/mic port | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Thunderbolt 4 ports quantity | 1 |
Design
| Specification | Value |
|---|---|
| Chassis type | 1.1L sized PC |
| Product colour | Black |
| VESA mounting | Yes |
| Product type | Mini PC barebone |
| Market positioning | Business |
Software
| Specification | Value |
|---|---|
| Operating system installed | No |
Power
| Specification | Value |
|---|---|
| Power supply type | External AC adapter |
| Power supply | 120 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 178.8 mm |
| Depth | 34.5 mm |
| Height | 179 mm |
| Weight | 1.1 kg |
| Package width | 530 mm |
| Package depth | 320 mm |
| Package height | 530 mm |
| Package weight | 2.1 kg |
Packaging content
| Specification | Value |
|---|---|
| Display included | No |
