P4W Z8
Model P4W Z8Part no. ITPCODP4WZ8-XXXX
31 specifications
- TypeMini PC barebone
- ColourBlack
- Built-in processorNo
- Supported memory clock speeds3200 MHz
- Supported storage drive typesSSD
- On-board graphics cardYes
Overview
- Type
- Mini PC barebone
- Colour
- Black
- Built-in processor
- No
- Supported memory clock speeds
- 3200 MHz
- Supported storage drive types
- SSD
- On-board graphics card
- Yes
- Brand
- itek
- Category
- PC/Workstation Barebones
- Model
- P4W Z8
- Part number
- ITPCODP4WZ8-XXXX
- Also known as
- itek P4W Z8 SFF Black
Specifications
31 specifications in 9 groups
Processor
| Specification | Value |
|---|---|
| Built-in processor | No |
Memory
| Specification | Value |
|---|---|
| Supported memory clock speeds | 3200 MHz |
| Supported memory types | DDR4-SDRAM |
Storage
| Specification | Value |
|---|---|
| Supported storage drive types | SSD |
| Storage drive sizes supported | 2.5" |
| Storage drive interface | Serial ATA III |
| NVMe | Yes |
| Card reader integrated | Yes |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | No |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 7 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| HDMI ports quantity | 1 |
| VGA (D-Sub) ports quantity | 0 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.4 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
Design
| Specification | Value |
|---|---|
| Chassis type | SFF |
| Product colour | Black |
| Cooling type | Active |
| Product type | Mini PC barebone |
Power
| Specification | Value |
|---|---|
| Power supply type | Internal power supply unit |
| Power supply | 300 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 95 mm |
| Depth | 283 mm |
| Height | 327 mm |
