ISY Call 4H

Model Call 4HPart no. ISYNUC4HC208000CALEAN 8055681881136

93 specifications

Overview

93 specifications in 15 groups

Specification	Value
Built-in processor	Yes
Processor manufacturer	Intel
Processor family	Intel® Celeron®
Processor model	N2820
Processor cores	2
Processor threads	2
Processor boost frequency	2.39 GHz
Processor frequency	2.13 GHz
Processor lithography	22 nm
L2 cache	1 MB
Thermal Design Power (TDP)	7.5 W
CPU configuration (max)	1
Processor codename	Bay Trail
Processor series	Intel Celeron Processor N2000 Series for Mobile

Specification	Value
Memory slots type	SO-DIMM
Internal memory	8 GB
Maximum internal memory	8 GB
Memory bandwidth (max)	8.53 GB/s
Memory channels	Single-channel
Memory voltage	1.35 V
Supported memory clock speeds	1066,1333,1600 MHz
Supported memory types	DDR3L-SDRAM

Specification	Value
Supported storage drive types	HDD & SSD
Storage drive sizes supported	2.5"
Number of storage drives supported	1

Specification	Value
On-board graphics card	Yes
Graphics card family	Intel
On-board graphics card model	Intel® HD Graphics
Number of displays supported	1

Specification	Value
Motherboard form factor	UCFF
Processor socket	BGA 1170
Number of processors supported	1
Compatible processor series	Intel® Celeron®
BIOS type	EEPROM
BIOS memory size	64 Mbit
Audio output channels	7.1 channels

Specification	Value
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
HDMI ports quantity	1
HDMI version	1.4a
VGA (D-Sub) ports quantity	0
Headphone outputs	1
Ethernet LAN (RJ-45) ports	1
DC-in jack	Yes

Specification	Value
PCI Express slots version	2.0
Mini PCI Express slots	1

Specification	Value
Conflict-Free	Yes
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Rapid Storage Technology	No
Intel Smart Connect Technology	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Identity Protection Technology (Intel® IPT)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® Quick Sync Video Technology	No
Intel® Turbo Boost Technology	No
Intel® Virtualization Technology (Intel® VT)	VT-x
Intel® Wireless Display (Intel® WiDi)	Yes

Specification	Value
Windows operating systems supported	Yes
Linux operating systems supported	Yes
Operating system installed	No

Specification	Value
Certification	UL 60950-1, CAN / CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, FCC 47 CFR Title I, Part 15 A / B, ICES-003, EN 55022, EN 55024, EN 55022, VCCI V-3, V-4, KN-2, KN-24, CNS 13438, CISPR 22, RoHS

Specification	Value
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-20 - 70 °C
