W291-Z00 Black LGA 4094
Model W291-Z00Part no. 6NW291Z00MR-00EAN 4719331281670
48 specifications
- TypeWorkstation barebone
- ColourBlack
- Built-in processorNo
- Processor socketLGA 4094
- Ethernet LANYes
- USB 2.0 ports quantity0
Overview
- Type
- Workstation barebone
- Colour
- Black
- Built-in processor
- No
- Processor socket
- LGA 4094
- Ethernet LAN
- Yes
- USB 2.0 ports quantity
- 0
- Brand
- GIGABYTE
- Category
- PC/Workstation Barebones
- Model
- W291-Z00
- Part number
- 6NW291Z00MR-00
- EAN / UPC
- 4719331281670
- Also known as
- GIGABYTE W291-Z00 Black LGA 4094
Specifications
48 specifications in 14 groups
Processor
| Specification | Value |
|---|---|
| Built-in processor | No |
Memory
| Specification | Value |
|---|---|
| Internal memory installed | No |
| Memory slots type | DIMM |
| Number of memory slots | 8 |
| Maximum internal memory | 128 GB |
| Memory channels | Quad-channel |
| Supported memory types | DDR4-SDRAM |
Storage
| Specification | Value |
|---|---|
| Storage drives installed | No |
| Supported storage drive types | HDD & SSD |
| Storage drive sizes supported | 2.5,3.5" |
| Number of storage drives supported | 5 |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | No |
Performance
| Specification | Value |
|---|---|
| Processor socket | LGA 4094 |
| Number of processors supported | 1 |
| Compatible processor series | AMD EPYC 7002 |
| Trusted Platform Module (TPM) | Yes |
Audio
| Specification | Value |
|---|---|
| Built-in speaker(s) | No |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | No |
| LAN controller | Intel® I210-AT |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| HDMI ports quantity | 0 |
| VGA (D-Sub) ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| PS/2 ports quantity | 1 |
| S/PDIF out port | Yes |
Expansion slots
| Specification | Value |
|---|---|
| Number of M.2 (M) slots | 1 |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Cooling type | Active |
| On/off switch | Yes |
| LED indicators | Yes |
| Product type | Workstation barebone |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Power
| Specification | Value |
|---|---|
| Power supply type | Internal power supply unit |
| AC input frequency | 47 - 63 Hz |
| AC input voltage | 100 - 240 V |
| Power supply | 1600 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 8 - 80% |
| Operating temperature (T-T) | 10 - 35 °C |
| Storage relative humidity (H-H) | 20 - 95% |
| Storage temperature (T-T) | -40 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 200 mm |
| Depth | 642.2 mm |
| Height | 450.2 mm |
| Package width | 348 mm |
| Package depth | 691 mm |
| Package height | 791 mm |
