GIGABYTE GB-BXCE-3205 PC/workstation barebone UCFF Black 3205U BGA 1168

1.5 GHz

Model GB-BXCE-3205EAN 889523000564

92 specifications

Overview

Brand: GIGABYTE
Category: PC/Workstation Barebones
Model: GB-BXCE-3205
Part number: GB-BXCE-3205
EAN / UPC: 889523000564, 4719331251246
Also known as: GIGABYTE GB-BXCE-3205 PC/workstation barebone UCFF Black 3205U BGA 1168 1.5 GHz

92 specifications in 14 groups

Specification	Value
Built-in processor	Yes
Processor manufacturer	Intel
Processor family	Intel® Celeron®
Processor model	3205U
Processor cores	2
Processor threads	2
Processor frequency	1.5 GHz
Processor lithography	14 nm
Thermal Design Power (TDP)	15 W
CPU configuration (max)	1
Processor codename	Broadwell
Processor series	Intel Celeron Processor 3000 series for Mobile

Specification	Value
Memory slots type	SO-DIMM
Number of memory slots	2
Maximum internal memory	16 GB
Memory voltage	1.35 V
Supported memory clock speeds	1333,1600 MHz
Supported memory types	DDR3L-SDRAM

Specification	Value
Supported storage drive types	SSD
Storage drive interface	mSATA
Number of storage drives supported	1

Specification	Value
Processor socket	BGA 1168
Number of processors supported	1
Compatible processor series	Intel® Celeron®
Optical drive type	No
Audio system	Realtek ALC283

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
HDMI ports quantity	1
VGA (D-Sub) ports quantity	0
Mini DisplayPorts quantity	1
Headphone outputs	1
Ethernet LAN (RJ-45) ports	1
DC-in jack	Yes

Specification	Value
PCI Express slots version	2.0
PCI Express configurations	2x4, 4x1

Specification	Value
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Clear Video Technology	Yes
Intel FDI Technology	Yes
Intel Fast Memory Access	Yes
Intel Flex Memory Access	Yes
Intel Stable Image Platform Program (SIPP)	No
Intel TSX-NI	No
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® InTru™ 3D Technology	Yes
Intel® Insider™	Yes
Intel® OS Guard	No
Intel® Quick Sync Video Technology	Yes
Intel® Secure Key	Yes
Intel® Small Business Advantage (Intel® SBA)	No
Intel® Smart Response Technology	No
Intel® Turbo Boost Technology	No
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
Intel® Wireless Display (Intel® WiDi)	Yes
Thermal Monitoring Technologies	Yes

Specification	Value
Windows operating systems supported	Yes
Operating system installed	No

Specification	Value
Operating temperature (T-T)	0 - 35 °C
Storage temperature (T-T)	-20 - 60 °C
