GIGABYTE GB-BXA8G-8890 PC/workstation barebone USFF Black, Red A8-5557M Socket FP2 (µBGA-827)
2.1 GHz
Model GB-BXA8G-8890EAN 132018219126
55 specifications
- ProcessorAMD A
- TypeMini PC barebone
- OSNo
- ColourBlack, Red
- Memory slots typeSO-DIMM
- Storage drive sizes supported2.5"
Overview
- Processor
- AMD A
- Type
- Mini PC barebone
- OS
- No
- Colour
- Black, Red
- Memory slots type
- SO-DIMM
- Storage drive sizes supported
- 2.5"
- Brand
- GIGABYTE
- Category
- PC/Workstation Barebones
- Model
- GB-BXA8G-8890
- Part number
- GB-BXA8G-8890
- EAN / UPC
- 132018219126, 818313018465, 8183130184658
- Also known as
- GIGABYTE GB-BXA8G-8890 PC/workstation barebone USFF Black, Red A8-5557M Socket FP2 (µBGA-827) 2.1 GHz
Specifications
55 specifications in 13 groups
Processor
| Specification | Value |
|---|---|
| Processor family | AMD A |
| Processor model | A8-5557M |
| Processor cores | 4 |
| Processor threads | 4 |
| Processor boost frequency | 3.5 GHz |
| Processor frequency | 2.1 GHz |
Memory
| Specification | Value |
|---|---|
| Memory slots type | SO-DIMM |
| Number of memory slots | 2 |
| Maximum internal memory | 16 GB |
| Supported memory clock speeds | 1333,1600 MHz |
| Supported memory types | DDR3-SDRAM |
Storage
| Specification | Value |
|---|---|
| Storage drive sizes supported | 2.5" |
| Storage drive interface | Serial ATA III |
| Card reader integrated | No |
Graphics
| Specification | Value |
|---|---|
| Graphics card family | AMD |
Performance
| Specification | Value |
|---|---|
| Processor socket | Socket FP2 (µBGA-827) |
| Supported processor frequency (max) | 3.2 GHz |
| Optical drive type | No |
| Audio system | Realtek ALC269 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Bluetooth | Yes |
| Bluetooth version | 4.0 |
| LAN controller | Realtek RTL8111G |
| Networking features | 802.11 a/b/g/n/ac |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| HDMI ports quantity | 1 |
| DVI port | No |
| Mini DisplayPorts quantity | 1 |
| Microphone in | No |
| Combo headphone/mic port | No |
| CardBus PCMCIA slot type | No |
| Ethernet LAN (RJ-45) ports | 1 |
| S/PDIF out port | No |
| DC-in jack | Yes |
Expansion slots
| Specification | Value |
|---|---|
| Mini PCI Express slots | 1 |
Design
| Specification | Value |
|---|---|
| Chassis type | USFF |
| Product colour | Black, Red |
| On/off switch | Yes |
| Panel mounting interface | 75 x 75,100 x 100 mm |
| Product type | Mini PC barebone |
Processor special features
| Specification | Value |
|---|---|
| Enhanced Intel SpeedStep Technology | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® Identity Protection Technology (Intel® IPT) | No |
| Intel® Small Business Advantage (Intel® SBA) | No |
| Intel® Smart Response Technology | No |
| Intel® Turbo Boost Technology | No |
| Intel® Wireless Display (Intel® WiDi) | No |
Software
| Specification | Value |
|---|---|
| Operating system installed | No |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 115.4 mm |
| Depth | 128 mm |
| Height | 59.6 mm |
Other features
| Specification | Value |
|---|---|
| Number of processors installed | 1 |
| Dimensions (WxDxH) | 111.4 x 114.4 x 62 mm |
| Power requirements | 100 - 240V AC |
