GB-BER7-5700 PC/workstation barebone Black 5700U
1.8 GHz
Model GB-BER7-5700EAN 4719331601195
63 specifications
- ProcessorAMD Ryzen™ 7
- SpeedWi-Fi 6 (802.11ax)
- TypeMini PC barebone
- ColourBlack
- Built-in processorYes
- Memory slots typeSO-DIMM
Overview
- Processor
- AMD Ryzen™ 7
- Speed
- Wi-Fi 6 (802.11ax)
- Type
- Mini PC barebone
- Colour
- Black
- Built-in processor
- Yes
- Memory slots type
- SO-DIMM
- Brand
- GIGABYTE
- Category
- PC/Workstation Barebones
- Model
- GB-BER7-5700
- Part number
- GB-BER7-5700
- EAN / UPC
- 4719331601195
- Also known as
- GIGABYTE GB-BER7-5700 PC/workstation barebone Black 5700U 1.8 GHz
Specifications
63 specifications in 14 groups
Processor
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor manufacturer | AMD |
| Processor family | AMD Ryzen™ 7 |
| Processor model | 5700U |
| Processor cores | 8 |
| Processor threads | 16 |
| Processor boost frequency | 4.3 GHz |
| Processor frequency | 1.8 GHz |
| Processor lithography | 7 nm |
| L2 cache | 4 MB |
| L3 cache | 8 MB |
| Thermal Design Power (TDP) | 15 W |
Memory
| Specification | Value |
|---|---|
| Memory slots type | SO-DIMM |
| Number of memory slots | 2 |
| Maximum internal memory | 64 GB |
| Supported memory clock speeds | 3200 MHz |
| Supported memory types | DDR4-SDRAM |
Storage
| Specification | Value |
|---|---|
| Supported storage drive types | SSD |
| Storage drive sizes supported | M.2 |
| Storage drive interface | PCI Express, Serial ATA |
| Number of storage drives supported | 1 |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| Graphics card family | AMD |
| On-board graphics card model | AMD Radeon Graphics |
Performance
| Specification | Value |
|---|---|
| Trusted Platform Module (TPM) | Yes |
| Audio chip | Realtek ALC897 |
Audio
| Specification | Value |
|---|---|
| Built-in speaker(s) | No |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| WLAN controller model | RZ608 |
| Bluetooth | Yes |
| Bluetooth version | 5.2 |
| LAN controller | Realtek RTL8125 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| HDMI ports quantity | 2 |
| HDMI version | 2.0b |
| VGA (D-Sub) ports quantity | 0 |
| DisplayPort version | 1.4 |
| Mini DisplayPorts quantity | 1 |
| Headphone outputs | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Yes |
Expansion slots
| Specification | Value |
|---|---|
| Number of M.2 (M) slots | 1 |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| On/off switch | Yes |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| VESA mounting | Yes |
| Product type | Mini PC barebone |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
Power
| Specification | Value |
|---|---|
| AC adapter output current | 6.92 A |
| AC adapter output voltage | 19.5 V |
| AC input voltage | 100 - 240 V |
| Power supply | 135 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 35 °C |
| Storage temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 139.1 mm |
| Depth | 134.2 mm |
| Height | 48.3 mm |
