Fujitsu CELSIUS M740
Model CELSIUS M740Part no. S26361-K1447-V355
49 specifications
- TypeWorkstation barebone
- Weight18 kg
- ColourBlack
- Built-in processorNo
- Memory slots typeDIMM
- Supported storage drive typesHDD & SSD
Overview
- Type
- Workstation barebone
- Weight
- 18 kg
- Colour
- Black
- Built-in processor
- No
- Memory slots type
- DIMM
- Supported storage drive types
- HDD & SSD
- Brand
- Fujitsu
- Category
- PC/Workstation Barebones
- Model
- CELSIUS M740
- Part number
- S26361-K1447-V355
- Also known as
- Fujitsu CELSIUS M740 Black Intel® C612 LGA 2011-v3
Specifications
49 specifications in 14 groups
Processor
| Specification | Value |
|---|---|
| Built-in processor | No |
Memory
| Specification | Value |
|---|---|
| Memory slots type | DIMM |
| Number of memory slots | 8 |
| Maximum internal memory | 256 GB |
| Supported memory clock speeds | 2400 MHz |
| Supported memory types | DDR4-SDRAM |
| ECC | Yes |
Storage
| Specification | Value |
|---|---|
| Supported storage drive types | HDD & SSD |
| Storage drive sizes supported | 2.5,3.5" |
| Number of storage drives supported | 9 |
| RAID levels | 0, 1, 5, 10 |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| Graphics card family | Intel |
Performance
| Specification | Value |
|---|---|
| Motherboard form factor | ATX |
| Motherboard chipset | Intel® C612 |
| Processor socket | LGA 2011-v3 |
| Number of processors supported | 1 |
| BIOS type | AMI |
| Built-in camera | No |
| Audio chip | Realtek ALC671 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| LAN controller | Intel® I217-LM |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 9 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 1 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express slots version | 2.0, 3.0 |
| PCI Express x1 slots | 2 |
| PCI Express x16 slots | 2 |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Cooling type | Active |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Product type | Workstation barebone |
| Number of 3.5" bays | 6 |
| Number of 5.25" bays | 1 |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
Certificates
| Specification | Value |
|---|---|
| Certification | GS, CE, FCC, cCSAus, RoHS, WEEE, EPEAT |
Power
| Specification | Value |
|---|---|
| Power supply type | Internal power supply unit |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 5 - 85% |
| Operating temperature (T-T) | 10 - 35 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 186 mm |
| Depth | 481 mm |
| Height | 430 mm |
| Weight | 18 kg |
| Package width | 397 mm |
| Package depth | 597 mm |
| Package height | 597 mm |
