ASUS VivoMini UN65H-M211M PC/workstation barebone

0.88L sized PC Blue i7-6500U LGA 1356 (Socket B2) 2.5 GHz

Model UN65H-M211M

80 specifications

ProcessorIntel® Core™ i7
Memory0 GB
TypeMini PC
OSNo
Weight700 g
ColourBlue

See all specifications

Overview

Processor: Intel® Core™ i7
Memory: 0 GB
Type: Mini PC
OS: No
Weight: 700 g
Colour: Blue

Brand: ASUS
Category: PC/Workstation Barebones
Model: UN65H-M211M
Part number: UN65H-M211M
Also known as: ASUS VivoMini UN65H-M211M PC/workstation barebone 0.88L sized PC Blue i7-6500U LGA 1356 (Socket B2) 2.5 GHz

Specifications

80 specifications in 16 groups

Processor

Specification	Value
Built-in processor	Yes
Processor manufacturer	Intel
Processor family	Intel® Core™ i7
Processor generation	6th gen Intel® Core™ i7
Processor model	i7-6500U
Processor cores	2
Processor threads	4
Processor boost frequency	3.1 GHz
Processor frequency	2.5 GHz
Processor lithography	14 nm
Thermal Design Power (TDP)	15 W
CPU configuration (max)	1
Processor codename	Skylake
Processor series	Intel Core i7-6500 Mobile series

Memory

Specification	Value
Memory slots type	SO-DIMM
Number of memory slots	2
Internal memory	0 GB
Maximum internal memory	32 GB
Supported memory clock speeds	1600 MHz
Supported memory types	DDR3L-SDRAM

Storage

Specification	Value
Card reader integrated	Yes
Compatible memory cards	SD, SDHC, SDXC, MMC

Graphics

Specification	Value
On-board graphics card	Yes

Performance

Specification	Value
Processor socket	LGA 1356 (Socket B2)

Network

Specification	Value
Ethernet LAN	Yes
Wi-Fi	Yes
Bluetooth	Yes

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
HDMI ports quantity	1
VGA (D-Sub) ports quantity	0
DisplayPorts quantity	1
Ethernet LAN (RJ-45) ports	1
DC-in jack	Yes

Expansion slots

Specification	Value
PCI Express slots version	3.0
PCI Express configurations	1x4, 4x1

Design

Specification	Value
Chassis type	0.88L sized PC
Product colour	Blue
Cooling type	Active
Product type	Mini PC

Processor special features

Specification	Value
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Clear Video Technology	Yes
Intel Flex Memory Access	Yes
Intel Stable Image Platform Program (SIPP)	No
Intel TSX-NI	No
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® InTru™ 3D Technology	Yes
Intel® Insider™	Yes
Intel® My WiFi Technology (Intel® MWT)	Yes
Intel® OS Guard	Yes
Intel® Quick Sync Video Technology	Yes
Intel® Secure Key	Yes
Intel® Small Business Advantage (Intel® SBA)	Yes
Intel® Smart Response Technology	Yes
Intel® Turbo Boost Technology	2.0
Intel® Wireless Display (Intel® WiDi)	Yes
Thermal Monitoring Technologies	Yes

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR

Software

Specification	Value
Operating system installed	No

Certificates

Specification	Value
Certification	BSMI/CE/FCC/UL/CCC/Energy Star/WiFi/RF/VCCI

Power

Specification	Value
Power supply	65 W

Weight & dimensions

Specification	Value
Width	131 mm
Depth	131 mm
Height	52 mm
Weight	700 g

Packaging content

Specification	Value
Display included	No
