TS300-E10-PS4 Full-Tower Black, Metallic Intel C246 LGA 1151 (Socket H4)
Model TS300-E10-PS4Part no. 90SF00S1-M00150EAN 4172017242493
55 specifications
- TypeWorkstation barebone
- Weight15 kg
- ColourBlack, Metallic
- Built-in processorNo
- Memory slots typeDIMM
- Supported storage drive typesHDD
Overview
- Type
- Workstation barebone
- Weight
- 15 kg
- Colour
- Black, Metallic
- Built-in processor
- No
- Memory slots type
- DIMM
- Supported storage drive types
- HDD
- Brand
- ASUS
- Category
- PC/Workstation Barebones
- Model
- TS300-E10-PS4
- Part number
- 90SF00S1-M00150
- EAN / UPC
- 4172017242493, 4718017242493
- Also known as
- ASUS TS300-E10-PS4 Full-Tower Black, Metallic Intel C246 LGA 1151 (Socket H4)
Specifications
55 specifications in 15 groups
Processor
| Specification | Value |
|---|---|
| Built-in processor | No |
Memory
| Specification | Value |
|---|---|
| Memory slots type | DIMM |
| Number of memory slots | 4 |
| Maximum internal memory | 128 GB |
| Supported memory clock speeds | 2400,2666 MHz |
Storage
| Specification | Value |
|---|---|
| Supported storage drive types | HDD |
| Storage drive sizes supported | 2.5,3.5" |
| SSD form factor | M.2 |
| Storage drive interface | PCI Express, SAS, Serial ATA |
| Number of storage drives supported | 4 |
| RAID levels | 0, 1, 5, 10 |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| On-board graphics card model | Aspeed AST2500 |
Performance
| Specification | Value |
|---|---|
| Motherboard chipset | Intel C246 |
| Processor socket | LGA 1151 (Socket H4) |
| Compatible processor series | Intel® Celeron®, Intel® Core™ i3, Intel® Pentium®, Intel® Xeon® |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | No |
| LAN controller | Intel® I210-AT |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| HDMI ports quantity | 0 |
| VGA (D-Sub) ports quantity | 1 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| COM ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 5 |
| Number of SATA III connectors | 8 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express slots version | 3.0 |
| PCI Express x8 slots | 2 |
| PCI Express x16 slots | 1 |
| PCI slots | 5 |
| Number of M.2 (M) slots | 2 |
Design
| Specification | Value |
|---|---|
| Chassis type | Full-Tower |
| Product colour | Black, Metallic |
| On/off switch | Yes |
| Product type | Workstation barebone |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84713000 |
Certificates
| Specification | Value |
|---|---|
| Certification | BSMI, CE |
Power
| Specification | Value |
|---|---|
| Power supply type | Internal power supply unit |
| AC adapter output current | 7 A |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Number of power supply units | 1 |
| Power supply | 500 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 20 - 90% |
| Operating temperature (T-T) | 10 - 35 °C |
| Storage temperature (T-T) | -40 - 70 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 217.5 mm |
| Depth | 545 mm |
| Height | 445 mm |
| Weight | 15 kg |
| Package weight | 18.9 kg |
