NUC 14 Essential RNUC14MNK2500003 Black N250
Model RNUC14MNK2500003Part no. 90AR00M2-M000N0EAN 197105790612
55 specifications
- ProcessorN250
- SpeedWi-Fi 6E (802.11ax)
- TypeMini PC barebone
- Weight470 g
- ColourBlack
- Built-in processorYes
Overview
- Processor
- N250
- Speed
- Wi-Fi 6E (802.11ax)
- Type
- Mini PC barebone
- Weight
- 470 g
- Colour
- Black
- Built-in processor
- Yes
- Brand
- ASUS
- Category
- PC/Workstation Barebones
- Model
- RNUC14MNK2500003
- Part number
- 90AR00M2-M000N0
- EAN / UPC
- 197105790612, 4711387790618
- Also known as
- ASUS NUC 14 Essential RNUC14MNK2500003 Black N250
Specifications
55 specifications in 11 groups
Processor
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor manufacturer | Intel |
| Processor model | N250 |
| Processor cores | 4 |
| Processor threads | 4 |
| Processor boost frequency | 3.8 GHz |
| Processor cache | 6 MB |
| Thermal Design Power (TDP) | 6 W |
Memory
| Specification | Value |
|---|---|
| Memory slots type | SO-DIMM |
| Maximum internal memory | 16 GB |
| Supported memory clock speeds | 4800 MHz |
Storage
| Specification | Value |
|---|---|
| Supported storage drive types | SSD |
| Storage drive sizes supported | M.2 |
| SSD form factor | M.2 |
| Storage drive interface | PCI Express, Serial ATA |
| NVMe | Yes |
| Number of storage drives supported | 4 |
| Maximum storage capacity | 8 TB |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| Graphics card family | Intel |
| On-board graphics card model | Intel® Graphics |
| Maximum resolution | 4096 x 2160 pixels |
| Number of displays supported | 3 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| LAN controller | Realtek RTL8125-BG, Realtek RTL8125-CG |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.4 |
| Headphone outputs | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Yes |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| VESA mounting | Yes |
| Product type | Mini PC barebone |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 11 |
| Linux operating systems supported | Yes |
Power
| Specification | Value |
|---|---|
| Power supply type | External AC adapter |
| AC adapter output current | 3.42 A |
| AC adapter output voltage | 19 V |
| Power supply | 65 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 135 mm |
| Depth | 115 mm |
| Height | 36 mm |
| Weight | 470 g |
Packaging content
| Specification | Value |
|---|---|
| Power cord included | Yes |
| AC adapter included | Yes |
