Pro ET900A X9
Model Pro ET900A X9Part no. PRO ET900A X9-B-2000EAN 197105709454
52 specifications
- TypeWorkstation barebone
- Weight31.5 kg
- ColourBlack
- Built-in processorNo
- Memory slots typeDIMM
- Supported storage drive typesHDD & SSD
Overview
- Type
- Workstation barebone
- Weight
- 31.5 kg
- Colour
- Black
- Built-in processor
- No
- Memory slots type
- DIMM
- Supported storage drive types
- HDD & SSD
- Brand
- ASUS
- Category
- PC/Workstation Barebones
- Model
- Pro ET900A X9
- Part number
- PRO ET900A X9-B-2000
- EAN / UPC
- 197105709454
- Also known as
- ASUS ExpertCenter Pro ET900A X9 Desktop Black AMD WRX90 Socket sTR5
Specifications
52 specifications in 15 groups
Processor
| Specification | Value |
|---|---|
| Built-in processor | No |
Memory
| Specification | Value |
|---|---|
| Memory slots type | DIMM |
| Number of memory slots | 8 |
| Memory channels | Octa-channel |
| Supported memory clock speeds | 4800,5600 MHz |
| Supported memory types | DDR5-SDRAM |
| ECC | Yes |
Storage
| Specification | Value |
|---|---|
| Supported storage drive types | HDD & SSD |
| Storage drive sizes supported | 2.5,3.5,M.2 |
| SSD form factor | M.2 |
| Storage drive interface | PCI Express, SAS, Serial ATA III |
| NVMe | Yes |
| Number of storage drives supported | 10 |
| RAID levels | 0, 1, 5, 10 |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | No |
Performance
| Specification | Value |
|---|---|
| Motherboard chipset | AMD WRX90 |
| Processor socket | Socket sTR5 |
| Number of processors supported | 1 |
| Compatible processor series | AMD Ryzen Threadripper PRO 5000 WX-Series |
Audio
| Specification | Value |
|---|---|
| Built-in speaker(s) | No |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | No |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 6 |
| USB4 Gen 2x2 ports quantity | 3 |
| HDMI ports quantity | 0 |
| VGA (D-Sub) ports quantity | 0 |
| Mini DisplayPorts quantity | 2 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x16 slots | 7 |
| Number of M.2 (M) slots | 4 |
Design
| Specification | Value |
|---|---|
| Chassis type | Desktop |
| Product colour | Black |
| Cooling type | Active |
| On/off switch | Yes |
| LED indicators | HDD, Power |
| Product type | Workstation barebone |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | BSMI, CE, Federal Communications Commission (FCC) |
Power
| Specification | Value |
|---|---|
| Power supply type | Internal power supply unit |
| Number of power supply units | 1 |
| Power supply | 2000 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Storage relative humidity (H-H) | 20 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 243 mm |
| Depth | 582 mm |
| Height | 532 mm |
| Weight | 31.5 kg |
| Package weight | 37.6 kg |
