Pro ET700I W7-B-750
Model Pro ET700I W7-B-750Part no. 90WS0011-M000P0EAN 4711387664582
61 specifications
- TypeWorkstation barebone
- Weight14.3 kg
- ColourBlack
- Built-in processorNo
- Motherboard chipsetIntel W790
- Ethernet LANYes
Overview
- Type
- Workstation barebone
- Weight
- 14.3 kg
- Colour
- Black
- Built-in processor
- No
- Motherboard chipset
- Intel W790
- Ethernet LAN
- Yes
- Brand
- ASUS
- Category
- PC/Workstation Barebones
- Model
- Pro ET700I W7-B-750
- Part number
- 90WS0011-M000P0
- EAN / UPC
- 4711387664582
- Also known as
- ASUS ExpertCenter Pro ET700I W7-B-750 Desktop Black Intel W790 LGA 4677 (Socket E)
Specifications
61 specifications in 15 groups
Processor
| Specification | Value |
|---|---|
| Built-in processor | No |
Memory
| Specification | Value |
|---|---|
| Internal memory installed | No |
| Memory slots type | DIMM |
| Number of memory slots | 8 |
| Maximum internal memory | 1 TB |
| Memory channels | Quad-channel |
| Supported memory clock speeds | 4400,4800 MHz |
| Supported memory types | DDR5-SDRAM |
| ECC | Yes |
Storage
| Specification | Value |
|---|---|
| Storage drives installed | No |
| Supported storage drive types | HDD & SSD |
| Storage drive sizes supported | 2.5,3.5,M.2 |
| SSD form factor | M.2 |
| Storage drive interface | PCI Express, SAS, Serial ATA III |
| NVMe | Yes |
| Number of storage drives supported | 8 |
| RAID levels | 0, 1, 5, 10 |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | No |
Performance
| Specification | Value |
|---|---|
| Motherboard chipset | Intel W790 |
| Processor socket | LGA 4677 (Socket E) |
| Number of processors supported | 1 |
| Compatible processor series | Intel® Xeon® |
Audio
| Specification | Value |
|---|---|
| Built-in speaker(s) | No |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | No |
| LAN controller | Intel I226-LM |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 6 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB4 Gen 2x2 ports quantity | 1 |
| HDMI ports quantity | 0 |
| VGA (D-Sub) ports quantity | 0 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Number of SATA III connectors | 4 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x4 slots | 1 |
| PCI Express x16 slots | 4 |
| Number of M.2 (M) slots | 2 |
Design
| Specification | Value |
|---|---|
| Chassis type | Desktop |
| Product colour | Black |
| Cooling type | Active |
| On/off switch | Yes |
| LED indicators | HDD, Power |
| Product type | Workstation barebone |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | BSMI, CE, Federal Communications Commission (FCC) |
Power
| Specification | Value |
|---|---|
| Power supply type | Internal power supply unit |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Number of power supply units | 1 |
| Power supply | 750 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Storage relative humidity (H-H) | 20 - 90% |
| Storage temperature (T-T) | -40 - 70 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 230 mm |
| Depth | 535 mm |
| Height | 448 mm |
| Weight | 14.3 kg |
| Package weight | 21.4 kg |
