PN63-S1-BB3000XFD Mini PC Black i3-1115G4
3 GHz
Model PN63-S1-BB3000XFDPart no. 90MR00Q1-M00040EAN 195553658874
53 specifications
- ProcessorIntel® Core™ i3
- Memory16 GB
- SpeedWi-Fi 6 (802.11ax)
- TypeMini PC
- Weight750 g
- ColourBlack
Overview
- Processor
- Intel® Core™ i3
- Memory
- 16 GB
- Speed
- Wi-Fi 6 (802.11ax)
- Type
- Mini PC
- Weight
- 750 g
- Colour
- Black
- Brand
- ASUS
- Category
- PC/Workstation Barebones
- Model
- PN63-S1-BB3000XFD
- Part number
- 90MR00Q1-M00040
- EAN / UPC
- 195553658874
- Also known as
- ASUS PN63-S1-BB3000XFD Mini PC Black i3-1115G4 3 GHz
Specifications
53 specifications in 12 groups
Processor
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i3 |
| Processor generation | 11th gen Intel® Core™ i3 |
| Processor model | i3-1115G4 |
| Processor cores | 2 |
| Processor frequency | 3 GHz |
| Processor cache | 6 MB |
Memory
| Specification | Value |
|---|---|
| Memory slots type | SO-DIMM |
| Number of memory slots | 2 |
| Internal memory | 16 GB |
| Maximum internal memory | 64 GB |
| Supported memory types | DDR4-SDRAM |
Storage
| Specification | Value |
|---|---|
| Supported storage drive types | HDD & SSD |
| Storage drive sizes supported | 2.5,M.2 |
| SSD form factor | M.2 |
| Storage drive interface | Serial ATA |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| Graphics card family | Intel |
| On-board graphics card model | Intel® UHD Graphics |
Performance
| Specification | Value |
|---|---|
| Optical drive type | No |
Audio
| Specification | Value |
|---|---|
| Built-in speaker(s) | No |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | Wi-Fi 6 (802.11ax) |
| Copper ethernet cabling technology | 2500BASE-T |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| HDMI ports quantity | 1 |
| VGA (D-Sub) ports quantity | 0 |
| DisplayPorts quantity | 1 |
| Mini DisplayPorts quantity | 1 |
| Combo headphone/mic port | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Yes |
Design
| Specification | Value |
|---|---|
| Chassis type | Mini PC |
| Product colour | Black |
| Cooling type | Active |
| Product type | Mini PC |
Power
| Specification | Value |
|---|---|
| Power supply type | External AC adapter |
| AC adapter output current | 4.74 A |
| AC adapter output voltage | 19 V |
| Power supply | 90 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 120 mm |
| Depth | 130 mm |
| Height | 58 mm |
| Weight | 750 g |
Packaging content
| Specification | Value |
|---|---|
| Display included | No |
