PN50-BBR747MD-CSM Black 4700U
2 GHz
Model PN50-BBR747MD-CSMPart no. 90MR00E1-M00170EAN 4718017788694
37 specifications
- ProcessorAMD Ryzen
- SpeedWi-Fi 6 (802.11ax)
- TypeMini PC barebone
- Weight700 g
- ColourBlack
- Built-in processorYes
Overview
- Processor
- AMD Ryzen
- Speed
- Wi-Fi 6 (802.11ax)
- Type
- Mini PC barebone
- Weight
- 700 g
- Colour
- Black
- Built-in processor
- Yes
- Brand
- ASUS
- Category
- PC/Workstation Barebones
- Model
- PN50-BBR747MD-CSM
- Part number
- 90MR00E1-M00170
- EAN / UPC
- 4718017788694
- Also known as
- ASUS PN50-BBR747MD-CSM Black 4700U 2 GHz
Specifications
37 specifications in 12 groups
Processor
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor manufacturer | AMD |
| Processor family | AMD Ryzen |
| Processor model | 4700U |
| Processor cores | 8 |
| Processor threads | 8 |
| Processor boost frequency | 4.1 GHz |
| Processor frequency | 2 GHz |
Memory
| Specification | Value |
|---|---|
| Memory slots type | SO-DIMM |
Storage
| Specification | Value |
|---|---|
| Supported storage drive types | HDD |
| Storage drive sizes supported | M.2 |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| On-board graphics card model | AMD Radeon Vega |
Performance
| Specification | Value |
|---|---|
| Audio chip | Realtek ALC3236-VB2 |
Display
| Specification | Value |
|---|---|
| Touchscreen | No |
Audio
| Specification | Value |
|---|---|
| Built-in speaker(s) | No |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | Wi-Fi 6 (802.11ax) |
| LAN controller | Realtek RTL8125-CG |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| HDMI ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
| DisplayPorts quantity | 1 |
| Combo headphone/mic port | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Product type | Mini PC barebone |
Power
| Specification | Value |
|---|---|
| Power supply type | External AC adapter |
| AC adapter output voltage | 19 V |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 115 mm |
| Depth | 115 mm |
| Height | 49 mm |
| Weight | 700 g |
