P2-M2A690G, Dark
Model P2-M2A690G, DarkPart no. P2-M2A690G DARK
32 specifications
- ProcessorAMD
- ColourBlack
- Memory slots typeDIMM
- Storage drive interfaceSerial ATA II
- On-board graphics cardYes
- Processor socketSocket AM2
Overview
- Processor
- AMD
- Colour
- Black
- Memory slots type
- DIMM
- Storage drive interface
- Serial ATA II
- On-board graphics card
- Yes
- Processor socket
- Socket AM2
- Brand
- ASUS
- Category
- PC/Workstation Barebones
- Model
- P2-M2A690G, Dark
- Part number
- P2-M2A690G DARK
- Also known as
- ASUS P2-M2A690G, Dark SFF Black Socket AM2
Specifications
32 specifications in 11 groups
Processor
| Specification | Value |
|---|---|
| Processor family | AMD |
Memory
| Specification | Value |
|---|---|
| Memory slots type | DIMM |
| Number of memory slots | 2 |
| Maximum internal memory | 2 GB |
Storage
| Specification | Value |
|---|---|
| Storage drive interface | Serial ATA II |
| Compatible memory cards | MMC, MS Pro, SD |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| Graphics card family | AMD |
| On-board graphics card model | AMD Radeon Xpress X1250 |
Performance
| Specification | Value |
|---|---|
| Processor socket | Socket AM2 |
| Audio output channels | 7.1 channels |
| Audio system | Realtek ALC883 |
Network
| Specification | Value |
|---|---|
| Networking features | Gigabit Ethernet |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 6 |
| HDMI ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Firewire (IEEE 1394) ports | 1 |
| PS/2 ports quantity | 2 |
| S/PDIF out port | Yes |
| Serial ports quantity | 1 |
Design
| Specification | Value |
|---|---|
| Chassis type | SFF |
| Product colour | Black |
Software
| Specification | Value |
|---|---|
| Compatible operating systems | Windows 2000/XP/Vista |
Power
| Specification | Value |
|---|---|
| Power supply | 200 W |
Other features
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 275 x 91 x 357 mm |
| Number of Parallel ATA connectors | 1 |
| Number of SATA connectors | 2 |
| Drive bays | 1 x 3.5", 1 x 5.25" |
| Expansion slots | 1x PCI, 1x PCI-e x1 |
