E900 G4
Model E900 G4Part no. 90SF00L1-M00610EAN 4718017354189
49 specifications
- TypeWorkstation barebone
- Weight18.3 kg
- ColourBlack
- Built-in processorNo
- Memory slots typeDIMM
- Supported storage drive typesHDD & SSD
Overview
- Type
- Workstation barebone
- Weight
- 18.3 kg
- Colour
- Black
- Built-in processor
- No
- Memory slots type
- DIMM
- Supported storage drive types
- HDD & SSD
- Brand
- ASUS
- Category
- PC/Workstation Barebones
- Model
- E900 G4
- Part number
- 90SF00L1-M00610
- EAN / UPC
- 4718017354189
- Also known as
- ASUS E900 G4 Black
Specifications
49 specifications in 14 groups
Processor
| Specification | Value |
|---|---|
| Built-in processor | No |
Memory
| Specification | Value |
|---|---|
| Memory slots type | DIMM |
| Number of memory slots | 12 |
| Maximum internal memory | 128 GB |
| Supported memory types | DDR4-SDRAM |
Storage
| Specification | Value |
|---|---|
| Supported storage drive types | HDD & SSD |
| Storage drive sizes supported | 2.5,3.5,M.2 |
| SSD form factor | M.2 |
| Storage drive interface | PCI Express, SAS, Serial ATA III |
| Number of storage drives supported | 8 |
| RAID levels | 0, 1, 5, 10 |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | No |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | No |
| LAN controller | Intel® I210-AT |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 8 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| HDMI ports quantity | 0 |
| VGA (D-Sub) ports quantity | 0 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| COM ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| PS/2 ports quantity | 1 |
| S/PDIF out port | Yes |
| Serial ports quantity | 8 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express slots version | 3.0 |
| PCI Express x16 slots | 7 |
| Number of M.2 (M) slots | 1 |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| LED indicators | HDD, Power, Reset |
| Product type | Workstation barebone |
| Number of 3.5" bays | 8 |
| Number of 5.25" bays | 2 |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84713000 |
Certificates
| Specification | Value |
|---|---|
| Certification | BSMI, CE, FCC(Class A) |
Power
| Specification | Value |
|---|---|
| Power supply type | Internal power supply unit |
| Power supply | 2000 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 20 - 90% |
| Operating temperature (T-T) | 10 - 35 °C |
| Storage temperature (T-T) | -40 - 70 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 532 mm |
| Depth | 243 mm |
| Height | 582 mm |
| Weight | 18.3 kg |
| Package weight | 23.1 kg |
