OLT1408A
Model OLT1408APart no. OLT1408A-ZZ02V1FEAN 4718937604180
17 specifications
- Weight4 kg
- DHCP relayYes
- 10G Ethernet ports quantity4
- AC input voltage100 - 240 V
- Operating temperature (T-T)-40 - 65 °C
- Width440 mm
Overview
- Weight
- 4 kg
- DHCP relay
- Yes
- 10G Ethernet ports quantity
- 4
- AC input voltage
- 100 - 240 V
- Operating temperature (T-T)
- -40 - 65 °C
- Width
- 440 mm
- Brand
- Zyxel
- Category
- Optical Line Terminals (OLTs)
- Model
- OLT1408A
- Part number
- OLT1408A-ZZ02V1F
- EAN / UPC
- 4718937604180
- Also known as
- Zyxel OLT1408A
Specifications
17 specifications in 5 groups
Features
| Specification | Value |
|---|---|
| DHCP relay | Yes |
| Multicast support | Yes |
| IGMP snooping | Yes |
| Quality of Service (QoS) support | Yes |
| Access Control List (ACL) | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ad, IEEE 802.1s, IEEE 802.1w |
| 10G Ethernet ports quantity | 4 |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100 - 240 V |
| DC voltage range | -36 - 70 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -40 - 65 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 95% |
| Storage relative humidity (H-H) | 10 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 440 mm |
| Depth | 250 mm |
| Height | 44 mm |
| Weight | 4 kg |
