Motorola ML-2499-BPDA1-01R network antenna Directional antenna N-type 24 dBi
Model ML-2499-BPDA1-01R
21 specifications
- Weight5.8 kg
- ColourWhite
- Antenna gain level (max)24 dBi
- Antenna typeDirectional antenna
- Operating temperature (T-T)-40 - 70 °C
- Diameter88.9 cm
Overview
- Weight
- 5.8 kg
- Colour
- White
- Antenna gain level (max)
- 24 dBi
- Antenna type
- Directional antenna
- Operating temperature (T-T)
- -40 - 70 °C
- Diameter
- 88.9 cm
- Brand
- Zebra
- Category
- Network Antenna
- Model
- ML-2499-BPDA1-01R
- Part number
- ML-2499-BPDA1-01R
- Also known as
- Motorola ML-2499-BPDA1-01R network antenna Directional antenna N-type 24 dBi
Specifications
21 specifications in 5 groups
Performance
| Specification | Value |
|---|---|
| Antenna gain level (max) | 24 dBi |
| Frequency band | 2.4 GHz |
| Networking standards | IEEE 802.11b, IEEE 802.11g |
| Antenna gain (2.4 GHz) | 24 dBi |
| Horizontal beam width (2.4 GHz) | 10° |
| Vertical beam width (2.4 GHz) | 10° |
Features
| Specification | Value |
|---|---|
| Antenna type | Directional antenna |
| Antenna connector type | N-type |
| Connector gender | Female |
| Polarization | Vertical polarization |
| Voltage Standing Wave Ratio (VSWR) | 1.7:1 |
| Product colour | White |
| Cable length | 0.3 m |
| Cable type | Coax |
| Power handling | 50 W |
| Purpose | Outdoor |
| Compatible products | AP-4131 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -40 - 70 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Diameter | 88.9 cm |
| Weight | 5.8 kg |
Other features
| Specification | Value |
|---|---|
| Frequency range | 2400 - 2500 MHz |
