20W USB-C GaN Charger, CH20 1.0
Model 20W USB-C GaN Charger, CH20 1.0Part no. CH20 1.0EAN 6971690793906
34 specifications
- Power20 W
- Weight43.2 g
- ColourWhite
- Charger typeIndoor
- Input voltage100 - 240 V
- Width28.1 mm
Overview
- Power
- 20 W
- Weight
- 43.2 g
- Colour
- White
- Charger type
- Indoor
- Input voltage
- 100 - 240 V
- Width
- 28.1 mm
- Brand
- Cudy
- Category
- Mobile Device Charger
- Model
- 20W USB-C GaN Charger, CH20 1.0
- Part number
- CH20 1.0
- EAN / UPC
- 6971690793906
- Also known as
- Cudy 20W USB-C GaN Charger, CH20 1.0 Universal White AC Fast charging Indoor
Specifications
34 specifications in 7 groups
Performance
| Specification | Value |
|---|---|
| Charger type | Indoor |
| Charger compatibility | Universal |
| Power source type | AC |
| USB Type-C ports quantity | 1 |
| Fast charging | Yes |
| Fast charging technology | Power Delivery 3.0 |
| Number of simultaneously connected devices (max) | 1 |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery revision | 3.0 |
| Power protection features | Overheating, Over voltage, Short circuit |
Design
| Specification | Value |
|---|---|
| Product colour | White |
| Gallium nitride (GaN) transistors | Yes |
Power
| Specification | Value |
|---|---|
| Input voltage | 100 - 240 V |
| Input frequency | 50 - 60 Hz |
| Input current | 0.7 A |
| Maximum power | 20 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 28.1 mm |
| Depth | 36.1 mm |
| Height | 39.5 mm |
| Weight | 43.2 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 88.5 mm |
| Package depth | 34 mm |
| Package height | 118 mm |
| Package weight | 81.4 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -10 - 25 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case net weight | 8.14 kg |
| Master (outer) case width | 465 mm |
| Master (outer) case length | 365 mm |
| Master (outer) case height | 260 mm |
| Master (outer) case gross weight | 9.44 kg |
| Products per master (outer) case | 100 pc(s) |
