TW1023ASC-B1P meeting room display
25.6 cm (10.1") 1280 x 800 pixels LED 802.11b, 802.11g, Wi-Fi 4 (802.11n) Bluetooth
Model TW1023ASC-B1PEAN 4948570117116
42 specifications
- Display25.6 cm (10.1")
- Resolution1280 x 800 pixels
- OSAndroid
- Weight800 g
- VESA mountingYes
- HDMI input ports quantity1
Overview
- Display
- 25.6 cm (10.1")
- Resolution
- 1280 x 800 pixels
- OS
- Android
- Weight
- 800 g
- VESA mounting
- Yes
- HDMI input ports quantity
- 1
- Brand
- iiyama
- Category
- Meeting Room Display
- Model
- TW1023ASC-B1P
- Part number
- TW1023ASC-B1P
- EAN / UPC
- 4948570117116
- Also known as
- iiyama TW1023ASC-B1P meeting room display 25.6 cm (10.1") 1280 x 800 pixels LED 802.11b, 802.11g, Wi-Fi 4 (802.11n) Bluetooth
Specifications
42 specifications in 12 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 25.6 cm (10.1") |
| Display resolution | 1280 x 800 pixels |
| Display technology | LED |
| Pixel pitch | 0.1692 x 0.1692 mm |
| Maximum refresh rate | 60 Hz |
| Response time | 25 ms |
| Display brightness | 385 cd/m² |
| Contrast ratio (typical) | 1000:1 |
| Touchscreen | Yes |
| Touchscreen technology | Projected capacitive system |
| Number of simultaneous touchpoints | 10 |
Design
| Specification | Value |
|---|---|
| VESA mounting | Yes |
| Panel mounting interface | 75 x 75 mm |
| Certification | CE, REACH |
Performance
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Operating system installed | Android |
Audio
| Specification | Value |
|---|---|
| Built-in microphone | Yes |
| Built-in speaker(s) | Yes |
| Number of speakers | 2 |
Camera
| Specification | Value |
|---|---|
| Built-in camera | Yes |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Bluetooth | Yes |
| Bluetooth version | 4.0 |
| Ethernet LAN | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI input ports quantity | 1 |
| HDMI ports quantity | 1 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 255 mm |
| Depth | 30.5 mm |
| Height | 172 mm |
| Weight | 800 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 398 mm |
| Package depth | 68 mm |
| Package height | 223 mm |
| Package weight | 1.36 kg |
Packaging content
| Specification | Value |
|---|---|
| Quick start guide | Yes |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ErP |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE, REACH, RoHS, WEEE |
| Pallet net height | 120 cm |
| Pallet net length | 2.15 m |
| Pallet net width | 100 cm |
| Products per pallet | 256 pc(s) |
