RF 24 mm f1.4L VCM
Model RF 24 mm f1.4L VCMPart no. 6907C006EAN 8714574690018
50 specifications Checked today
- Weight515 g
- ColourBlack
- Component forMILC
- AF actuatorNano USM, VCM
- Diameter7.65 cm
Overview
- Weight
- 515 g
- Colour
- Black
- Component for
- MILC
- AF actuator
- Nano USM, VCM
- Diameter
- 7.65 cm
- Brand
- Canon
- Category
- Lens
- Model
- RF 24 mm f1.4L VCM
- Part number
- 6907C006
- EAN / UPC
- 8714574690018
- Also known as
- Canon RF 24 mm f1.4L VCM MILC Wide lens Black
Specifications
50 specifications in 7 groups
Lens system
| Specification | Value |
|---|---|
| Component for | MILC |
| Lens structure (elements/groups) | 15/11 |
| Lens type | Wide lens |
| Lens viewing angle, horizontal | 74° |
| Focus adjustment | Auto/Manual |
| Lens viewing angle, vertical | 53° |
| Fixed focal length | 24 mm |
| Lens viewing angle, diagonal | 84° |
| Closest focusing distance | 0.24 m |
| Control ring | Yes |
| Image sensor format | Full frame |
| Lens mount interface | Canon RF |
| Maximum aperture number | 1.4 |
| Minimum aperture number | 16 |
| Number of aspheric elements | 1 |
| Number of diaphragm blades | 11 |
| Teleconverter/Extender compatible | No |
| Zoom capability | No |
| Image stabilizer | Yes |
| Image stabilizer type | In-Body Image Stabilization (IBIS), Optical Image Stabilization (OIS) |
| Image stabilizer number of stops (IBIS x OIS) | 8 |
Performance
| Specification | Value |
|---|---|
| AF actuator | Nano USM, VCM |
| Auto focus | Yes |
| Camera brands compatibility | Canon |
| Circular aperture | Yes |
| Lens coating features | Air Sphere Coating (ASC), Subwavelength Structure Coating (SWC), Super Spectra Coating (SSC) |
| Manual focus | Yes |
| Maximum magnification | 0.17x |
| Number of Ultra-low Dispersion (UD) elements | 2 |
| Ultrasonic motor (USM) | Yes |
| Lens hood | Yes |
| Lens hood type | Removable lens hood |
| Lens hood model | EW-73G |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Mounting type | Bayonet |
| Dustproof | Yes |
| Moisture-resistant | Yes |
Logistics data
| Specification | Value |
|---|---|
| Layers per pallet | 3 pc(s) |
Weight & dimensions
| Specification | Value |
|---|---|
| Diameter | 7.65 cm |
| Filter size | 67 mm |
| Length | 99.3 mm |
| Weight | 515 g |
Packaging data
| Specification | Value |
|---|---|
| Package depth | 137 mm |
| Package height | 265 mm |
| Package weight | 900 g |
| Package width | 137 mm |
Packaging content
| Specification | Value |
|---|---|
| Lens cap included | Yes |
| Lens cap model | E-67II |
| Rear lens cap included | Yes |
| Rear lens cap model | RF |
