Lenovo Legion 5 15IMH05
Lenovo

Legion 5 15IMH05

Model Legion 5 15IMH05Part no. 82AU00ALPBEAN 195042700879

137 specifications Checked today
  • Display39.6 cm (15.6")
  • Resolution1920 x 1080 pixels
  • ProcessorIntel® Core™ i7
  • Memory16 GB
  • Storage512 GB
  • GraphicsNVIDIA® GeForce® GTX 1650 Ti
See all specifications

Overview

Display
39.6 cm (15.6")
Resolution
1920 x 1080 pixels
Processor
Intel® Core™ i7
Memory
16 GB
Storage
512 GB
Graphics
NVIDIA® GeForce® GTX 1650 Ti
Brand
Lenovo
Category
Laptop
Model
Legion 5 15IMH05
Part numbers
82AU00ALPB, 82AU0031MH, 82AU0045UK, 82AU0047UK, 82AU0046UK, 82AU00BTUS +34 more
EAN / UPC
195042700879, 194778959506, 195042339314, 195042339338 +56 more
Also known as
Lenovo Legion 5 15IMH05 Intel® Core™ i7 i7-10750H Laptop 39.6 cm (15.6") Full HD 16 GB DDR4-SDRAM 512 GB SSD NVIDIA® GeForce® GTX 1650 Ti Wi-Fi 6 (802.11ax) Win

Specifications

137 specifications in 18 groups

Design

Product typeLaptop
Product colourBlack
Form factorClamshell
Housing materialAcrylonitrile butadiene styrene (ABS), Polycarbonate (PC)
Market positioningGaming

Display

Display diagonal39.6 cm (15.6")
Display resolution1920 x 1080 pixels
TouchscreenNo
HD typeFull HD
Panel typeIPS
LED backlightYes
Native aspect ratio16:9
Display brightness250 cd/m²
Maximum refresh rate120 Hz

Processor

Processor manufacturerIntel
Processor familyIntel® Core™ i7
Processor generation10th gen Intel® Core™ i7
Processor modeli7-10750H
Processor cores6
Processor threads12
Processor boost frequency5 GHz
Processor frequency2.6 GHz
System bus rate8 GT/s
Processor cache12 MB
Processor cache typeSmart Cache
Processor socketBGA 1440
Processor lithography14 nm
Processor operating modes64-bit
Processor codenameComet Lake
Thermal Design Power (TDP)45 W
Configurable TDP-down35 W
Tjunction100 °C
Maximum number of PCI Express lanes16
PCI Express configurations1x16, 2x8, 1x8+2x4
PCI Express slots version3.0

Memory

Internal memory16 GB
Internal memory typeDDR4-SDRAM
Memory clock speed2933 MHz
Memory form factorSO-DIMM
Memory slots2x SO-DIMM
Maximum internal memory16 GB

Storage

Total storage capacity512 GB
Storage mediaSSD
Total SSDs capacity512 GB
Number of SSDs installed1
SSD capacity512 GB
Optical drive typeNo
Card reader integratedNo

Graphics

On-board graphics cardYes
Discrete graphics cardYes
Discrete graphics card modelNVIDIA® GeForce® GTX 1650 Ti
Discrete graphics card memory4 GB
Discrete graphics memory typeGDDR6
On-board graphics card modelIntel® UHD Graphics
On-board graphics card base frequency350 MHz
On-board graphics card dynamic frequency (max)1150 MHz
On-board graphics card DirectX version12.0
On-board graphics card OpenGL version4.5
On-board graphics card ID0x9BC4

Audio

Audio chipRealtek ALC3287
Number of built-in speakers2
Speaker power2 W
Built-in subwooferNo
Built-in microphoneYes
Number of microphones2

Camera

Front cameraYes
Front camera resolution (numeric)1 MP
Front camera HD typeHD
Privacy cameraYes
Privacy typePrivacy shutter

Network

Mobile network connectionNo
Top Wi-Fi standardWi-Fi 6 (802.11ax)
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Antenna type2x2
Ethernet LANYes
Ethernet LAN data rates10,100,1000 Mbit/s
BluetoothYes
Bluetooth version5.0
WWANNot installed

Ports & interfaces

USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity1
Ethernet LAN (RJ-45) ports1
HDMI ports quantity1
HDMI version2.0
Combo headphone/mic portYes
USB Sleep-and-ChargeYes
USB Sleep-and-Charge ports1

Keyboard

Pointing deviceTouchpad
Keyboard backlitYes
Numeric keypadYes

Software

Operating system installedWindows 10 Home
Operating system architecture64-bit

Processor special features

CPU configuration (max)1
Embedded options availableNo
Enhanced Intel SpeedStep TechnologyYes
Execute Disable BitYes
Idle StatesYes
Intel 64Yes
Intel Flex Memory AccessYes
Intel Software Guard Extensions (Intel SGX)Yes
Intel Stable Image Platform Program (SIPP)No
Intel Trusted Execution TechnologyNo
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Identity Protection Technology (Intel® IPT)Yes
Intel® OS GuardYes
Intel® Quick Sync Video TechnologyYes
Intel® Secure KeyYes
Processor ARK ID201837
Processor package size42 x 28 mm
Supported instruction setsSSE4.1, SSE4.2, AVX 2.0
Thermal Monitoring TechnologiesYes

Battery

Battery technologyLithium Polymer (LiPo)
Battery capacity60 Wh
Battery life (max)6.8 h
Fast chargingYes
Fast charging time (50%)30 min

Power

AC adapter power170 W
AC adapter frequency50 - 60 Hz
AC adapter input voltage100 - 240 V
DC-in jackYes

Security

Cable lock slotYes
Fingerprint readerNo
Trusted Platform Module (TPM)Yes
Password protectionYes
Password protection typeHDD, Power on, Supervisor

Certificates

Compliance certificatesRoHS
CertificationErP lot3

Weight & dimensions

Weight2.3 kg
Width363.1 mm
Depth259.6 mm
Height (front)2.36 cm
Height (rear)2.61 cm
