m15 R2
Alienware

m15 R2

Model m15 R2Part no. N00AWM15R204EAN 5397184286197

208 specifications Checked today
  • Display39.6 cm (15.6")
  • Resolution1920 x 1080 pixels
  • ProcessorIntel® Core™ i7
  • Memory16 GB
  • Storage512 GB
  • GraphicsNVIDIA® GeForce RTX™ 2060
See all specifications

Overview

Display
39.6 cm (15.6")
Resolution
1920 x 1080 pixels
Processor
Intel® Core™ i7
Memory
16 GB
Storage
512 GB
Graphics
NVIDIA® GeForce RTX™ 2060
Brand
Alienware
Category
Laptop
Model
m15 R2
Part numbers
N00AWM15R204, N00AWM15R210, N00AWM15R207, N00AWM15R203, N00AWM15R208, WNM15R2070SBUN +34 more
EAN / UPC
5397184286197, 5397184286203, 5397184327753, 5397184327746 +8 more
Also known as
Alienware m15 R2 Intel® Core™ i7 i7-9750H Laptop 39.6 cm (15.6") Full HD 16 GB DDR4-SDRAM 512 GB SSD NVIDIA® GeForce RTX™ 2060 Wi-Fi 5 (802.11ac) Windows 10 Hom

Specifications

208 specifications in 24 groups

Design

Product typeLaptop
Product colourBlack, White
Colour nameLunar Light
Form factorClamshell
Market positioningGaming

Display

Display diagonal39.6 cm (15.6")
Display resolution1920 x 1080 pixels
TouchscreenNo
HD typeFull HD
LED backlightYes
Native aspect ratio16:9
Display brightness300 cd/m²
Pixel density141 ppi
Pixel pitch0.17925 x 0.17925 mm
Dual-screenNo
Maximum refresh rate144 Hz

Processor

Processor manufacturerIntel
Processor familyIntel® Core™ i7
Processor generation9th gen Intel® Core™ i7
Processor modeli7-9750H
Processor cores6
Processor threads12
Processor boost frequency4.5 GHz
Processor frequency2.6 GHz
System bus rate8 GT/s
Processor cache12 MB
Processor cache typeSmart Cache
Processor socketBGA 1440
Processor lithography14 nm
Processor operating modes64-bit
Processor codenameCoffee Lake
Thermal Design Power (TDP)45 W
Configurable TDP-down35 W
Tjunction100 °C
Maximum number of PCI Express lanes16
PCI Express configurations1x16, 2x8, 1x8+2x4
PCI Express slots version3.0

Memory

Internal memory16 GB
Internal memory typeDDR4-SDRAM
Memory clock speed2666 MHz
Memory form factorOn-board
Memory layout (slots x size)2 x 8 GB
Maximum internal memory16 GB
Maximum internal memory (64-bit)16 GB

Storage

Total storage capacity512 GB
Storage mediaSSD
Total SSDs capacity512 GB
Number of SSDs installed1
SSD capacity512 GB
SSD interfacePCI Express
SSD form factorM.2
Optical drive typeNo
Card reader integratedNo

Graphics

On-board graphics cardYes
Discrete graphics cardYes
Discrete graphics card modelNVIDIA® GeForce RTX™ 2060
Discrete graphics card memory6 GB
Discrete graphics memory typeGDDR6
On-board graphics card modelIntel® UHD Graphics 630
Maximum on-board graphics card memory64 GB
On-board graphics card base frequency350 MHz
On-board graphics card dynamic frequency (max)1150 MHz
On-board graphics card DirectX version12.0
On-board graphics card OpenGL version4.5
On-board graphics card ID0x3E9B
Number of discrete graphics cards installed1
CUDAYes
CUDA cores1920

Audio

Audio chipRealtek ALC3281-CG
Number of built-in speakers2
Speaker power2 W
Built-in microphoneYes

Camera

Front cameraYes
Front camera resolution (numeric)0.92 MP
Front camera HD typeHD
Front camera resolution1280 x 720 pixels
Front camera signal format720p
Video capturing speed30 fps

Network

Wi-FiYes
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Wi-Fi standardsWi-Fi 5 (802.11ac)
Antenna type2x2
WLAN controller modelIntel Dual Band Wireless-AC 8265
Ethernet LANYes
Ethernet LAN data rates1000,2500 Mbit/s
BluetoothYes
Bluetooth version4.2
MIMOYes
MIMO typeMulti User MIMO

Ports & interfaces

USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0
Ethernet LAN (RJ-45) ports1
HDMI ports quantity1
HDMI version2.0
DisplayPorts quantity0
Mini DisplayPorts quantity1
Thunderbolt 3 ports quantity1
Thunderbolt™ 3 TechnologyYes
Combo headphone/mic portYes
Alienware graphics amplifier portYes
PowerShareYes
Number of USB ports with PowerShare support1

Performance

Virtual Reality (VR) readyYes
Motherboard chipsetIntel® HM370
Repairability index6.9

Keyboard

Pointing deviceTouchpad
Keyboard backlitYes
Numeric keypadNo
Keyboard backlit colourVarious
Windows keysYes
Keyboard languageFrench

Software

Operating system installedWindows 10 Home
Operating system architecture64-bit
Operating system languageMultilingual
Bundled softwareFinancial Tracker & Retail Information

Processor special features

CPU configuration (max)1
Embedded options availableNo
Enhanced Intel SpeedStep TechnologyYes
Execute Disable BitYes
Idle StatesYes
Intel 64Yes
Intel Clear Video TechnologyYes
Intel Flex Memory AccessYes
Intel Software Guard Extensions (Intel SGX)Yes
Intel Stable Image Platform Program (SIPP)No
Intel TSX-NINo
Intel Trusted Execution TechnologyNo
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Clear Video HD Technology (Intel® CVT HD)Yes
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Identity Protection Technology (Intel® IPT)Yes
Intel® InTru™ 3D TechnologyYes
Intel® My WiFi Technology (Intel® MWT)Yes
Intel® OS GuardYes
Intel® Quick Sync Video TechnologyYes
Intel® Secure KeyYes
Intel® Turbo Boost Technology2.0
Processor ARK ID191045
Processor package size42 x 28 mm
Supported instruction setsSSE4.1, SSE4.2, AVX 2.0
Thermal Monitoring TechnologiesYes

Battery

Number of battery cells6
Battery capacity76 Wh
Battery voltage11.4 V
Battery recharge time4 h
Battery weight320 g

Power

AC adapter power180 W
AC adapter frequency50 - 60 Hz
AC adapter input voltage100 - 240 V
AC adapter output current9.23 A
AC adapter output voltage19.5 V
DC-in jackYes

Security

Cable lock slotYes
Cable lock slot typeNoble
Password protectionYes

Operational conditions

Operating temperature (T-T)0 - 35 °C
Storage temperature (T-T)-40 - 65 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)0 - 95%
Operating altitude-15.2 - 3048 m
Non-operating altitude-15.2 - 10668 m
Operating shock110 G
Non-operating shock160 G
Operating vibration0.66 G
Non-operating vibration1.3 G

Weight & dimensions

Weight2.16 kg
Width360.5 mm
Depth276 mm
Height (front)1.79 cm
Height (rear)1.95 cm

Packaging data

Package width408 mm
Package depth455 mm
Package height117 mm
Package weight4.75 kg
Package materialCorrugated cardboard, Polypropylene (PP)

Recycling data

Paper molded pulp content per package0 g
Bamboo molded pulp content per package0 g
Wheat straw molded pulp content per package0 g
Grey board content per package0 g
Corrugated cardboard content per package1.34 kg
Corrugated cardboard content per shipping (inner) case945 g
Corrugated cardboard content per box for accessories200 g
Corrugated cardboard content per sleeve for accessories193 g
Polyethylene terephthalate (PET) content per package0 g
High-density polyethylene (HDPE) content per package0 g
Low-density polyethylene (LDPE) content per package0 g
Polypropylene (PP) content per package19 g
Polystyrene (PS) content per package0 g
Other materials content per package117 g

Packaging content

AC adapter includedYes
ManualYes
Power cord includedYes

Logistics data

Maximum number of stacking cartons4 pc(s)
Products per pallet layer20 pc(s)
Layers per pallet2 pc(s)
Products per pallet40 pc(s)
Pallet gross width100 cm
Pallet gross length120 cm
Pallet gross weight198 kg
Pallet volume weight75 kg
Products per intermodal container (20ft)800 pc(s)
Products per intermodal container (40ft)1680 pc(s)

Other features

EPEAT rating90.77%
Package volume weight3.63 kg
