ASUS ProArt StudioBook 16 OLED H7604JV-MY135X-P Intel® Core™ i9 i9-13980HX Laptop

ProArt StudioBook 16 OLED H7604JV-MY135X-P Intel® Core™ i9 i9-13980HX Laptop

40.6 cm (16") Touchscreen 3.2K 64 GB DDR5-SDRAM 1 TB SSD NVIDIA GeForce RTX 40

Model H7604JV-MY135X-PPart no. 90NB10C2-M005W0EAN 197105573215

121 specifications Checked today

Display40.6 cm (16")
Resolution3200 x 2000 pixels
ProcessorIntel® Core™ i9
Memory64 GB
Storage1 TB
GraphicsNVIDIA GeForce RTX 4060

See all specifications

Overview

Display: 40.6 cm (16")
Resolution: 3200 x 2000 pixels
Processor: Intel® Core™ i9
Memory: 64 GB
Storage: 1 TB
Graphics: NVIDIA GeForce RTX 4060

Brand: ASUS
Category: Laptop
Model: H7604JV-MY135X-P
Part number: 90NB10C2-M005W0
EAN / UPC: 197105573215, 4711387573211
Also known as: ASUS ProArt StudioBook 16 OLED H7604JV-MY135X-P Intel® Core™ i9 i9-13980HX Laptop 40.6 cm (16") Touchscreen 3.2K 64 GB DDR5-SDRAM 1 TB SSD NVIDIA GeForce RTX 40

Specifications

121 specifications in 18 groups

Design

Specification	Value
Product type	Laptop
Product colour	Black
Colour name	Mineral Black
Form factor	Clamshell
Housing material	Aluminium, Magnesium

Display

Specification	Value
Display diagonal	40.6 cm (16")
Display resolution	3200 x 2000 pixels
Touchscreen	Yes
HD type	3.2K
Panel type	OLED
Native aspect ratio	16:10
Display surface	Gloss
Display brightness	500 cd/m²
Maximum display brightness (HDR)	550 cd/m²
Colour gamut	100%
RGB colour space	DCI-P3
Display response rise/fall	0.2 ms
Maximum refresh rate	120 Hz
Contrast ratio (typical)	1000000:1
High Dynamic Range (HDR) supported	Yes
High Dynamic Range (HDR) technology	HDR True Black 500

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i9
Processor generation	13th gen Intel® Core™ i9
Processor model	i9-13980HX
Processor cores	24
Processor boost frequency	5.6 GHz
Performance cores	8
Efficient cores	16
Performance-core Max Turbo Frequency	5.6 GHz
Efficient-core Max Turbo Frequency	4 GHz
Processor cache	36 MB
Processor cache type	Smart Cache
Maximum turbo power	157 W
Processor base power	55 W

Memory

Specification	Value
Internal memory	64 GB
Internal memory type	DDR5-SDRAM
Memory form factor	SO-DIMM
Memory layout (slots x size)	2 x 32 GB
Memory slots	2x SO-DIMM
Maximum internal memory	64 GB

Storage

Specification	Value
Total storage capacity	1 TB
Storage media	SSD
Total SSDs capacity	1 TB
Number of SSDs installed	1
SSD capacity	1 TB
NVMe	Yes
SSD interface	PCI Express 4.0
SSD form factor	M.2
Optical drive type	No
Card reader integrated	Yes
Compatible memory cards	SD

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card	Yes
Discrete GPU manufacturer	NVIDIA
Discrete graphics card model	NVIDIA GeForce RTX 4060
Discrete graphics card memory	8 GB
Discrete graphics memory type	GDDR6
On-board GPU manufacturer	Intel
On-board graphics card family	Intel® UHD Graphics
On-board graphics card model	Intel® UHD Graphics

Audio

Specification	Value
Audio system	Smart Amp
Speakers manufacturer	Harman Kardon
Built-in microphone	Yes

Camera

Specification	Value
Front camera	Yes
Front camera HD type	Full HD
Front camera resolution	1920 x 1080 pixels
Infrared (IR) camera	Yes
Privacy camera	Yes
Privacy type	Privacy shutter

Network

Specification	Value
Mobile network connection	No
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Wi-Fi standards	Wi-Fi 6E (802.11ax)
Antenna type	2x2
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Bluetooth	Yes
Bluetooth version	5.3

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	1
HDMI version	2.1
Thunderbolt 4 ports quantity	2
Intel® Thunderbolt 4	Yes
Combo headphone/mic port	Yes
Power adapter barrel connector	6.0 mm
USB Type-C DisplayPort Alternate Mode	Yes

Keyboard

Specification	Value
Pointing device	Touchpad
Keyboard backlit	Yes
Numeric keypad	Yes
Keyboard layout	QWERTY
Keyboard language	Dutch

Software

Specification	Value
Operating system installed	Windows 11 Pro
Operating system architecture	64-bit
Trial software	1-month trial for new Microsoft 365 customers. Credit card required, McAfee 30 days

Battery

Specification	Value
Battery technology	Lithium-Ion (Li-Ion)
Number of battery cells	4
Battery capacity	90 Wh

Power

Specification	Value
AC adapter power	240 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	12 A
AC adapter output voltage	20 V
USB Power Delivery (USB PD)	Yes

Security

Specification	Value
Cable lock slot	Yes
Face recognition	Yes
Windows Hello	Yes
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0
Password protection	Yes
Password protection type	BIOS, HDD, User

Certificates

Specification	Value
Compliance certificates	REACH, RoHS

Sustainability

Specification	Value
Sustainability compliance	Yes

Weight & dimensions

Specification	Value
Weight	2.4 kg
Width	356 mm
Depth	271 mm
Height (front)	2.09 cm
Height (rear)	2.39 cm
