Acer SpatialLabs Edition PH3D15-71-9690

SpatialLabs Edition PH3D15-71-9690

Model SpatialLabs Edition PH3D15-71-9690Part no. NH.QLWEH.003EAN 4711121619915

90 specifications Checked today

Display39.6 cm (15.6")
Resolution1920 x 2160 pixels
ProcessorIntel® Core™ i9
Memory32 GB
Storage1 TB
GraphicsNVIDIA GeForce RTX 4080

See all specifications

Overview

Display: 39.6 cm (15.6")
Resolution: 1920 x 2160 pixels
Processor: Intel® Core™ i9
Memory: 32 GB
Storage: 1 TB
Graphics: NVIDIA GeForce RTX 4080

Brand: Acer
Category: Laptop
Model: SpatialLabs Edition PH3D15-71-9690
Part number: NH.QLWEH.003
EAN / UPC: 4711121619915
Also known as: Acer Predator Helios 3D 15 SpatialLabs Edition PH3D15-71-9690 Intel® Core™ i9 i9-13900HX Laptop 39.6 cm (15.6") 32 GB DDR5-SDRAM 1 TB SSD NVIDIA GeForce RTX 408

Specifications

90 specifications in 16 groups

Design

Specification	Value
Product type	Laptop
Product colour	Black
Form factor	Clamshell
Market positioning	Gaming

Display

Specification	Value
Display diagonal	39.6 cm (15.6")
Display resolution	1920 x 2160 pixels
Touchscreen	No
Panel type	IPS
LED backlight	Yes
Native aspect ratio	16:9
Colour gamut	100%
Display diagonal (metric)	39.6 cm
RGB colour space	Adobe RGB

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i9
Processor generation	13th gen Intel® Core™ i9
Processor model	i9-13900HX
Processor cores	24
Processor threads	32
Processor boost frequency	5.4 GHz
Processor frequency	2.2 GHz
Processor cache	36 MB
Processor cache type	L3

Memory

Specification	Value
Internal memory	32 GB
Internal memory type	DDR5-SDRAM
Memory clock speed	5600 MHz
Memory slots	2x SO-DIMM
Maximum internal memory	32 GB
Memory channels	Dual-channel

Storage

Specification	Value
Total storage capacity	1 TB
Storage media	SSD
Total SSDs capacity	1 TB
Number of SSDs installed	1
SSD capacity	1 TB
NVMe	Yes
SSD interface	PCI Express
SSD form factor	M.2
Self-Encrypting Drive (SED)	Yes
Optical drive type	No
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card	Yes
Discrete graphics card model	NVIDIA GeForce RTX 4080
Discrete graphics card memory	12 GB
Discrete graphics memory type	GDDR6
On-board graphics card model	Intel® UHD Graphics

Audio

Specification	Value
Audio system	DTS:X Ultra
Number of built-in speakers	2
Built-in microphone	Yes

Camera

Specification	Value
Front camera	Yes
Front camera HD type	HD

Network

Specification	Value
Mobile network connection	No
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Wi-Fi standards	Wi-Fi 6E (802.11ax)
Antenna type	2x2
WLAN controller manufacturer	Killer
WLAN controller model	Killer Wi-Fi 6E 1675i
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Bluetooth	Yes

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	2
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	1
Combo headphone/mic port	Yes

Keyboard

Specification	Value
Pointing device	Touchpad
Keyboard backlit	Yes
Numeric keypad	Yes
Keyboard backlit colour	RGB
Keyboard layout	QWERTY

Software

Specification	Value
Operating system installed	Windows 11 Home

Battery

Specification	Value
Battery technology	Lithium-Ion (Li-Ion)
Number of battery cells	4
Battery capacity	90 Wh
Battery life (max)	4.5 h

Power

Specification	Value
AC adapter power	330 W
DC-in jack	Yes

Security

Specification	Value
Cable lock slot	Yes
Cable lock slot type	Kensington
Trusted Platform Module (TPM)	Yes
Password protection	Yes
Password protection type	BIOS, HDD, Supervisor, User

Weight & dimensions

Specification	Value
Weight	2.98 kg
Width	359.4 mm
Depth	280.8 mm
Height	27.9 mm
