Acer Chromebook Plus 514 CB514-5H Traditional Laptop - Intel Core 5 120U

Chromebook Plus 514 CB514-5H Traditional Laptop - Intel Core 5 120U

8GB, 512GB SSD, Integrated Graphics, 14" WUXGA, Chrome OS, Iron

Model NX.JKAEK.004EAN 4711474495686

96 specifications Checked today

Display35.6 cm (14")
Resolution1920 x 1200 pixels
ProcessorIntel Core 5
Memory8 GB
Storage512 GB
GraphicsNot available

See all specifications

Overview

Display: 35.6 cm (14")
Resolution: 1920 x 1200 pixels
Processor: Intel Core 5
Memory: 8 GB
Storage: 512 GB
Graphics: Not available

Brand: Acer
Category: Laptop
Model: NX.JKAEK.004
Part number: NX.JKAEK.004
EAN / UPC: 4711474495686
Also known as: Acer Chromebook Plus 514 CB514-5H Traditional Laptop - Intel Core 5 120U, 8GB, 512GB SSD, Integrated Graphics, 14" WUXGA, Chrome OS, Iron

Specifications

96 specifications in 18 groups

Design

Specification	Value
Product type	Chromebook
Product colour	Grey
Colour name	Iron
Form factor	Clamshell
Market positioning	Consumer
Country of origin	China

Display

Specification	Value
Display diagonal	35.6 cm (14")
Display resolution	1920 x 1200 pixels
Touchscreen	No
HD type	WUXGA
Display technology marketing name	ComfyView
Panel type	IPS
LED backlight	Yes
Native aspect ratio	16:10
Display surface	Matt
Maximum refresh rate	60 Hz

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Core 5
Processor generation	Intel Core (Series 1)
Processor model	120U
Processor cores	10
Processor threads	12
Processor boost frequency	5 GHz
Processor frequency	1.4 GHz
Performance cores	2
Efficient cores	8
Performance-core Max Turbo Frequency	5 GHz
Efficient-core Max Turbo Frequency	3.8 GHz
Performance-core base frequency	1.4 GHz
Efficient-core base frequency	0.9 GHz
Processor cache	12 MB
Processor cache type	Smart Cache

Neural processor unit (NPU)

Specification	Value
Neural processor unit (NPU)	No

Memory

Specification	Value
Internal memory	8 GB
Internal memory type	LPDDR5-SDRAM
Maximum internal memory	8 GB

Storage

Specification	Value
Total storage capacity	512 GB
Storage media	SSD
Total SSDs capacity	512 GB
Number of SSDs installed	1
SSD capacity	512 GB
NVMe	Yes
SSD interface	M.2, PCI Express 4.0
SSD form factor	M.2

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card	No
Discrete graphics card model	Not available
On-board graphics card model	Intel® Graphics

Audio

Specification	Value
Audio system	DTS Audio Processing
Number of built-in speakers	2
Built-in microphone	Yes
Number of microphones	3
Microphone modes	Voice Isolation

Camera

Specification	Value
Front camera	Yes
Front camera resolution (numeric)	5 MP
Front camera HD type	Quad HD
Front camera resolution	2560 x 1440 pixels

Network

Specification	Value
Mobile network connection	No
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
Wi-Fi band	Tri-band (2.4 GHz / 5 GHz / 6 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Antenna type	2x2
WLAN controller manufacturer	Intel
WLAN controller model	Intel Wi-Fi 7 BE200
MIMO	Yes
MIMO type	Multi User MIMO

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	2
HDMI ports quantity	1
HDMI version	1.4
Headphone outputs	1
Combo headphone/mic port	Yes
Microphone in	Yes
USB Type-C DisplayPort Alternate Mode	Yes

Keyboard

Specification	Value
Pointing device	Touchpad
Keyboard backlit	Yes
Numeric keypad	No
Keyboard backlit colour	White

Software

Specification	Value
Operating system installed	ChromeOS

Battery

Specification	Value
Battery technology	Lithium-Ion (Li-Ion)
Number of battery cells	3
Battery capacity	53 Wh
Battery life (max)	13 h

Power

Specification	Value
AC adapter power	65 W
USB Type-C charging port	Yes

Security

Specification	Value
Trusted Platform Module (TPM)	Yes

Weight & dimensions

Specification	Value
Weight	1.41 kg
Width	316.4 mm
Depth	226.5 mm
Height	18.4 mm

Packaging data

Specification	Value
Package width	457 mm
Package depth	288 mm
Package height	65 mm
Package weight	2.34 kg
