Electrolux EFL10566DX Island Stainless steel 660 m³/h
Model EFL10566DXPart no. 942 492 837EAN 7332543392155
42 specifications
- Energy classC
- Noise63 dB
- TypeIsland
- ColourStainless steel
- Maximum extraction power660 m³/h
- Grease filter typeAluminium
Overview
- Energy class
- C
- Noise
- 63 dB
- Type
- Island
- Colour
- Stainless steel
- Maximum extraction power
- 660 m³/h
- Grease filter type
- Aluminium
- Brand
- Electrolux
- Category
- Cooker Hood
- Model
- EFL10566DX
- Part number
- 942 492 837
- EAN / UPC
- 7332543392155
- Also known as
- Electrolux EFL10566DX Island Stainless steel 660 m³/h
Specifications
42 specifications in 7 groups
Performance
| Specification | Value |
|---|---|
| Maximum extraction power | 660 m³/h |
| Type of extraction | Ducted |
| Fluid dynamic efficiency class | C |
| Lighting efficiency class | E |
| Grease filtering efficiency class | B |
| Boost position air extraction power | 685 m³/h |
| Number of speeds | 3 |
| Intensive speed | Yes |
| Noise level (high speed) | 63 dB |
| Noise level (low speed) | 45 dB |
| Noise level (intensive speed) | 68 dB |
| Airflow (low speed) | 315 m³/h |
Design
| Specification | Value |
|---|---|
| Type | Island |
| Product colour | Stainless steel |
| Housing material | Stainless steel |
| Built-in display | No |
| Control type | Buttons |
| Exhaust location | Top |
| Exhaust connection diameter | 15 cm |
| Number of motors | 1 |
| Motor included | Yes |
Filtering
| Specification | Value |
|---|---|
| Grease filter type | Aluminium |
| Number of filters | 3 pc(s) |
| Filter cleaning indicator | Yes |
| Removable filter | Yes |
| Washable filter | Yes |
Lighting
| Specification | Value |
|---|---|
| Number of bulbs | 4 bulb(s) |
| Bulb type | Halogen |
| Lighting efficiency (LE) | 9 lux/W |
Power
| Specification | Value |
|---|---|
| Energy efficiency class | C |
| Motor power | 140 W |
| Power consumption (off) | 0.49 W |
| Annual energy consumption | 122.3 kWh |
| AC input frequency | 50 Hz |
| AC input voltage | 220-240 V |
| Energy efficiency class (legacy scale) | C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 998 mm |
| Depth | 700 mm |
| Height (min) | 91 cm |
| Height (max) | 115 cm |
Other features
| Specification | Value |
|---|---|
| Fluid dynamic efficiency (FDE) | 19.9 |
| Grease filtering efficiency (GFE) | 90% |
