NDE566DB Semi built-in (pull out) Black 560 m³/h
Model NDE566DBPart no. 942 490 781EAN 7333394051178
60 specifications
- Energy classA+
- Noise65 dB
- TypeSemi built-in (pull out)
- Weight10 kg
- ColourBlack
- Maximum extraction power560 m³/h
Overview
- Energy class
- A+
- Noise
- 65 dB
- Type
- Semi built-in (pull out)
- Weight
- 10 kg
- Colour
- Black
- Maximum extraction power
- 560 m³/h
- Brand
- AEG
- Category
- Cooker Hood
- Model
- NDE566DB
- Part number
- 942 490 781
- EAN / UPC
- 7333394051178
- Also known as
- AEG NDE566DB Semi built-in (pull out) Black 560 m³/h
Specifications
60 specifications in 9 groups
Performance
| Specification | Value |
|---|---|
| Maximum extraction power | 560 m³/h |
| Type of extraction | Ducted/Recirculating |
| Fluid dynamic efficiency class | A |
| Lighting efficiency class | A |
| Grease filtering efficiency class | C |
| Boost position air extraction power | 680 m³/h |
| Number of speeds | 3 |
| Intensive speed | Yes |
| Noise level | 65 dB |
| Noise level (high speed) | 65 dB |
| Noise level (low speed) | 52 dB |
| Noise level (medium speed) | 65 dB |
| Noise level (intensive speed) | 67 dB |
| Airflow (low speed) | 290 m³/h |
| Pressure (Pa) | 550 |
| Minimum distance from electric hob | 50 cm |
| Minimum distance from gas hob | 54 cm |
Design
| Specification | Value |
|---|---|
| Type | Semi built-in (pull out) |
| Colour name | Nero |
| Product colour | Black |
| Hob²Hood function | No |
| Breeze function | No |
| Built-in display | No |
| Control type | Touch |
| Cord length | 1.5 m |
| Exhaust location | Top |
| Exhaust connection diameter | 15 cm |
| Number of motors | 1 |
Filtering
| Specification | Value |
|---|---|
| Grease filter type | Stainless steel |
| Number of filters | 2 pc(s) |
| Washable filter | Yes |
Lighting
| Specification | Value |
|---|---|
| Number of bulbs | 1 bulb(s) |
| Bulb type | LED |
| Colour temperature | 3000 K |
| Dimmable lighting | Yes |
| Lighting efficiency (LE) | 98.3 lux/W |
Power
| Specification | Value |
|---|---|
| Energy efficiency class | A+ |
| Energy efficiency scale | A+++ to D |
| Motor power | 265 W |
| Power consumption (off) | 0.49 W |
| Power consumption (standby) | 0.49 W |
| Annual energy consumption | 30.9 kWh |
| AC input frequency | 50 Hz |
| AC input voltage | 220-240 V |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 562 mm |
| Depth | 309 mm |
| Height | 338 mm |
| Height (max) | 33.8 cm |
| Height without chimney | 8.5 cm |
| Weight | 10 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 670 mm |
| Package depth | 410 mm |
| Package height | 440 mm |
| Package weight | 15 kg |
Brand-specific features
| Specification | Value |
|---|---|
| AEG technologies (air extraction) | Washable Grease Filter |
Other features
| Specification | Value |
|---|---|
| Fluid dynamic efficiency (FDE) | 34.9 |
| Grease filtering efficiency (GFE) | 80.2% |
| Measured air pressure at best efficiency point | 482 Pa |
| Country of origin | Italy |
| Filter | MCFB90 | - |
