4-Port USB 3.0 Extender Hub with 1x Gigabit Ethernet Port Extension over Single Cat6a/Cat7 Cable (RJ45) - 330ft (100m) - USB Extender Kit (USB-A) -
Model USB3004EXT2EAN 065030880688
36 specifications
- TypeConsole transmitter & receiver
- Weight990 g
- ColourBlack
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
- Width137 mm
- Operating temperature (T-T)0 - 50 °C
Overview
- Type
- Console transmitter & receiver
- Weight
- 990 g
- Colour
- Black
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
- 4
- Width
- 137 mm
- Operating temperature (T-T)
- 0 - 50 °C
- Brand
- StarTech.com
- Category
- Console Extender
- Model
- USB3004EXT2
- Part number
- USB3004EXT2
- EAN / UPC
- 065030880688
- Also known as
- StarTech.com 4-Port USB 3.0 Extender Hub with 1x Gigabit Ethernet Port Extension over Single Cat6a/Cat7 Cable (RJ45) - 330ft (100m) - USB Extender Kit (USB-A) -
Specifications
36 specifications in 7 groups
Technical details
| Specification | Value |
|---|---|
| Type | Console transmitter & receiver |
| Data transfer rate | 5000 Mbit/s |
| Maximum transfer distance | 100 m |
| Product colour | Black |
| Cable types supported | Cat6a, Cat7 |
| Compliance certificates | CE, RoHS |
| Housing material | Aluminium |
| LED indicators | Activity, Link, Power, Status |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity | 1 |
| RJ-45 ports quantity | 4 |
| DC-in jack | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 137 mm |
| Depth | 232 mm |
| Height | 33 mm |
| Weight | 990 g |
| Package width | 214 mm |
| Package depth | 261 mm |
| Package height | 173 mm |
| Package weight | 3.9 kg |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 20 - 80% |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Cables included | USB Type-A to USB Type-B |
| Mounting kit | Yes |
| Quick start guide | Yes |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 24 W |
| Input voltage | 100 - 240 V |
| Input current | 0.58 A |
| Output voltage | 24 V |
| Output current | 1 A |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case width | 370 mm |
| Master (outer) case length | 450 mm |
| Master (outer) case height | 290 mm |
| Products per master (outer) case | 4 pc(s) |
