150m USB 2.0 Cat.6 Extender
Model 43391EAN 4002888433914
30 specifications
- TypeConsole transmitter & receiver
- ColourBlack
- USB 2.0 Type-A ports quantity1
- Width67 mm
- Operating temperature (T-T)0 - 50 °C
- Power source typeDC
Overview
- Type
- Console transmitter & receiver
- Colour
- Black
- USB 2.0 Type-A ports quantity
- 1
- Width
- 67 mm
- Operating temperature (T-T)
- 0 - 50 °C
- Power source type
- DC
- Brand
- Lindy
- Category
- Console Extender
- Model
- 43391
- Part number
- 43391
- EAN / UPC
- 4002888433914
- Also known as
- Lindy 150m USB 2.0 Cat.6 Extender
Specifications
30 specifications in 6 groups
Technical details
| Specification | Value |
|---|---|
| Type | Console transmitter & receiver |
| Data transfer rate | 480 Mbit/s |
| Maximum transfer distance | 150 m |
| Product colour | Black |
| Cable types supported | Cat6 |
| Compliance certificates | CE, Federal Communications Commission (FCC), REACH, RoHS |
| Housing material | Metal |
| LED indicators | Activity, Power |
| Plug and Play | Yes |
| Sustainability compliance | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 Type-A ports quantity | 1 |
| USB 2.0 Type-B ports quantity | 1 |
| RJ-45 ports quantity | 2 |
| DC-in jack | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 67 mm |
| Depth | 32 mm |
| Height | 25 mm |
| Transmitter weight | 84 g |
| Receiver weight | 84 g |
| Package width | 220 mm |
| Package depth | 194 mm |
| Package height | 60 mm |
| Package weight | 600 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| Output voltage | 5 V |
| Output current | 3 A |
