UCE32100 console extender Console transmitter & receiver 25 Mbit/s
Model UCE32100EAN 672792010569
25 specifications
- TypeConsole transmitter & receiver
- Weight210 g
- ColourBlack
- USB 2.0 Type-A ports quantity4
- Width79 mm
- Operating temperature (T-T)0 - 50 °C
Overview
- Type
- Console transmitter & receiver
- Weight
- 210 g
- Colour
- Black
- USB 2.0 Type-A ports quantity
- 4
- Width
- 79 mm
- Operating temperature (T-T)
- 0 - 50 °C
- Brand
- ATEN
- Category
- Console Extender
- Model
- UCE32100
- Part numbers
- UCE32100, UCE32100-AT-E
- EAN / UPC
- 672792010569
- Also known as
- ATEN UCE32100 console extender Console transmitter & receiver 25 Mbit/s
Specifications
25 specifications in 7 groups
Technical details
| Specification | Value |
|---|---|
| Type | Console transmitter & receiver |
| Data transfer rate | 25 Mbit/s |
| Ethernet LAN | Yes |
| Maximum transfer distance | 100 m |
| Product colour | Black |
| Cable types supported | Cat5 |
| Housing material | Metal |
| LED indicators | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 Type-A ports quantity | 4 |
| USB 2.0 Type-B ports quantity | 1 |
| RJ-45 ports quantity | 1 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 79 mm |
| Depth | 101.5 mm |
| Height | 24.4 mm |
| Weight | 210 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 0 - 80% |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Cables included | AC, USB |
| Manual | Yes |
| Mounting kit | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| Input voltage | 5 V |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84733020 |
